| Ref | Part Number | Description |
| 1 |
8413-675 |
Screw, Cap Price: $3.38 |
| 2 |
2623-025 |
Washer Price: $1.45 |
| 4 |
3604-033 |
Bearing Price: $13.95 |
| 5 |
0623-946 |
Ring, Retaining Price: $2.26 |
| 6 |
8413-620 |
Screw, Cap Price: $1.08 |
| 7 |
3604-899 |
Block, Mounting - Idler Wheel Price: $9.64 |
| 8 |
8427-602 |
Nut, Hex Price: $0.23 |
| 9 |
8422-602 |
Nut Price: $0.48 |
| 10 |
1423-064 |
BOLT, HFH M10-1.25X250 CL10.9 RIE SILVER Price: $17.29 |
| 11 |
3604-083 |
Spacer Price: $13.28 |
| 12 |
0623-912 |
Washer Price: $1.07 |
| 13 |
3604-269 |
Axle Price: $64.95 |
| 14 |
1623-992 |
Washer, Internal Tooth Lock Price: $0.35 |
| 15 |
8422-002 |
Nut, Lock Price: $1.08 |
| 16 |
8408-031 |
Screw, Cap Price: $2.30 |
| 17 |
1623-931 |
Washer Price: $1.70 |
| 18 |
3604-641 |
Bushing, Adjuster Price: $7.23 |
| 19 |
4604-137 |
Wheel, Idler - Tri-Hub - 8.00 w/0.787 ID Price: $72.95 |
| 20 |
3604-640 |
Axle, Rear Price: $57.95 |
| 21 |
8476-620 |
Screw, Machine This part replaces 8408-620. Price: $0.48 |
| 22 |
3604-647 |
Adjuster, Track Price: $3.80 |
| 23 |
8422-802 |
Nut, Lock Price: $0.46 |
