| Ref | Part Number | Description |
|---|
| 30 |
204100201 |
PHILLIPS SCREW 1/4-20 X 1-1/4 - Call your local BRP dealership |
| 80 |
211000054 |
HEX. SCREW 1/4-20 X 1?, SCOTCH GRIP - Call your local BRP dealership |
| 85 |
211200025 |
Lock Washer 1/4” |
| 90 |
234082600 |
Flat Washer 8 mm, Stainless |
| 105 |
204611531 |
RETAINING CLIP - Call your local BRP dealership |
| 110 |
204613998 |
SEAT SUPPORT - Call your local BRP dealership |
| 115 |
293150043 |
Pop Rivet 3/16" |
| 120 |
234061600 |
Stainless Flat Washer M6 |
| 130 |
293150008 |
Pop Rivet 3/16" This part replaces 293150011. |
| 135 |
204615050 |
BALL FASTENER/NYLON - Call your local BRP dealership |
| 140 |
204615051 |
SOCKET FASTENER/NYLON - Call your local BRP dealership |
| 145 |
204100054 |
SCREW 8 X 3/4? - Call your local BRP dealership |
| 150 |
204611940 |
SEAT LATCH - Call your local BRP dealership |
| 160 |
204100039 |
SCREW 1/4?-20 X 2? - Call your local BRP dealership |
| 180 |
204611805 |
LATCH - Call your local BRP dealership |
| 190 |
204100219 |
SCREW-PAN HD.#10-32 X 1-1/4 SS - Call your local BRP dealership |
| 205 |
XXX |
Not Available As Spare Parts |
| 210 |
XXX |
Not Available As Spare Parts |
| 215 |
XXX |
Not Available As Spare Parts |
| 235 |
204130264 |
Dart 1", White |
| 240 |
XXX |
Not Available As Spare Parts |
| 245 |
XXX |
Not Available As Spare Parts |
| 250 |
XXX |
Not Available As Spare Parts |
| 255 |
XXX |
Not Available As Spare Parts |
| 260 |
XXX |
Not Available As Spare Parts |
| 270 |
XXX |
Not Available As Spare Parts |
| 275 |
XXX |
Not Available As Spare Parts |
| 280 |
XXX |
Not Available As Spare Parts |
| 285 |
XXX |
Not Available As Spare Parts |
| 290 |
XXX |
Not Available As Spare Parts |
| 295 |
XXX |
Not Available As Spare Parts |
| 305 |
204100058 |
Phillips Tapping Screw |
| 310 |
204615049 |
Retention Cord With Clip |
| 330 |
204614709 |
SEAT SUPPORT ASS'Y - Call your local BRP dealership |
| 335 |
208564060 |
PHILLIPS SCREW M6 X 40 - Call your local BRP dealership |
| 340 |
234062600 |
Flat Washer M6, Stainless |
| 345 |
232561600 |
Hex. Elastic Stop Nut M6 |
| 360 |
204130166 |
LOCATOR STUD - Call your local BRP dealership |
| 365 |
205053560 |
SOCKET SCREW M5 X 35 - Call your local BRP dealership |
| 485 |
269002156 |
Lower Knee Pad |
| 525 |
269002160 |
SIDE FLAT BACKREST, STARBOARD - Call your local BRP dealership |
| 535 |
234082600 |
Flat Washer 8 mm, Stainless |
| 540 |
211100026 |
HEX. NUT 1/4 - Call your local BRP dealership |
| 550 |
269001696 |
SEAT SUPPORT - Call your local BRP dealership |
| 555 |
293150029 |
RIVET_POP 5/32 - Call your local BRP dealership |
| 565 |
204100030 |
Phillips Screw #8 X 1/2” |
| 570 |
205364060 |
SOCKET HEAD SCREW M6 X 40 - Call your local BRP dealership |
| 575 |
204614766 |
HINGE SHIM - Call your local BRP dealership |
| 580 |
234062600 |
Flat Washer M6, Stainless |
| 585 |
232561600 |
Hex. Elastic Stop Nut M6 |
| 590 |
269001995 |
HINGE BRACKET SET - Call your local BRP dealership |
| 595 |
211100026 |
HEX. NUT 1/4 - Call your local BRP dealership |
| 615 |
204130008 |
Plastic Cap, White |
| 685 |
204610750 |
BACKREST HINGE - Call your local BRP dealership |
| 690 |
204100049 |
PHILLIPS TAPPING SCREW #8 X 1 - Call your local BRP dealership |
| 695 |
293150008 |
Pop Rivet 3/16" This part replaces 293150011. |
| 765 |
204614762 |
HOLDER - Call your local BRP dealership |
| 770 |
204100054 |
SCREW 8 X 3/4? - Call your local BRP dealership |
| 775 |
269002153 |
HOLDER DOOR ASS'Y - Call your local BRP dealership |
| 780 |
204100220 |
Pan Head Screw 10-32 X 1/2" |
| 785 |
212100005 |
Hex. Nut |
| 790 |
204100236 |
SCREW-HEX.HD.MACHINE #10 X 1 - Call your local BRP dealership |
| 795 |
211200033 |
FLAT WASHER - Call your local BRP dealership |
| 850 |
269002161 |
ELBOWREST ASSY/STBD - Call your local BRP dealership |
| 1010 |
234082600 |
Flat Washer 8 mm, Stainless |
| 1015 |
211200025 |
Lock Washer 1/4” |
| 1020 |
211100026 |
HEX. NUT 1/4 - Call your local BRP dealership |
| 1040 |
204130008 |
Plastic Cap, White |
| 1060 |
204614762 |
HOLDER - Call your local BRP dealership |
| 1065 |
204100054 |
SCREW 8 X 3/4? - Call your local BRP dealership |
| 1070 |
269002153 |
HOLDER DOOR ASS'Y - Call your local BRP dealership |
| 1075 |
204100220 |
Pan Head Screw 10-32 X 1/2" |
| 1080 |
212100005 |
Hex. Nut |
| 1090 |
204100236 |
SCREW-HEX.HD.MACHINE #10 X 1 - Call your local BRP dealership |
| 1095 |
211200033 |
FLAT WASHER - Call your local BRP dealership |
