| Ref | Part Number | Description |
|---|
| 2 |
M5145379 |
Handle Support |
| 3 |
207064044 |
Hex. Screw M6 X 40 |
| 4 |
233261414 |
Hex. Flange Elastic Nut M6 x 1.0 This part replaces M33200. |
| 5 |
M28136 |
PLUG - Call your local BRP dealership |
| 6 |
605354720 |
Snow Guard This part replaces M539945. |
| 7 |
M5341770 |
Support |
| 8 |
36037 |
Black Rivet This part replaces M36037. |
| 9 |
M5340136 |
Snow Guard |
| 10 |
M5340532 |
Support |
| 11 |
M36097 |
RIVET - Call your local BRP dealership |
| 12 |
Not |
Available As Spare Part - Hitch Ass'y |
| 13 |
5344151 |
Fitting Plate This part replaces M5344151. |
| 14 |
548745 |
TONGUE WELD - Call your local BRP dealership This part replaces M548745. |
| 15 |
560309200 |
PIN-RETAINER - Call your local BRP dealership |
| 16 |
41031 |
Cotter Pin This part replaces M41031. |
| 17 |
40336 |
HEX. SCREW M8 X 20 - Call your local BRP dealership This part replaces M40336. |
| 18 |
232581414 |
Hex. Elastic Stop Nut M8 |
| 19 |
Not |
Available As Spare Part - Rear Lamp Ass'y |
| 20 |
510004061 |
LIGHT HOUSING - Call your local BRP dealership |
| 21 |
520000758 |
Bulb This part replaces 410504100. |
| 22 |
414513700 |
Lens |
| 23 |
414516400 |
Washer - Call your local BRP dealership |
| 24 |
233261414 |
Hex. Flange Elastic Nut M6 x 1.0 This part replaces M33200. |
| 25 |
209632540 |
Phillips Tapping Screw M3.9 X 25 This part replaces 414516300. |
| 26 |
409010600 |
FEMALE TERMINAL - Call your local BRP dealership This part replaces M42178. |
| 27 |
409010400 |
Female Terminal Housing, 1 Circuit This part replaces M42179. |
| 28 |
207063044 |
Hex. Screw M6 X 30 |
| 29 |
M5345713 |
Adaptor |
| 30 |
515175852 |
Adapter |
| 31 |
M39023 |
Housing |
| 32 |
M5346331 |
Foam |
| 33 |
M5246336 |
Welded Seat Base Weld |
| 34 |
36005 |
Rivet This part replaces M36005. |
| 35 |
20008 |
Washer 5,3 mm This part replaces M20008. |
| 36 |
605153077 |
COVER SEAT - Call your local BRP dealership This part replaces 605148727. |
| 37 |
M5245239 |
Foam Seat |
| 38 |
M390002 |
Cushion |
| 39 |
M5346383 |
LATCH - Call your local BRP dealership |
| 40 |
M5446848 |
PLATE - Call your local BRP dealership |
| 41 |
605449087 |
Counter Roller |
| 42 |
40168 |
Slot Sc. M4 X 25 Din966M4.8Zne(1=10Pcs) This part replaces M40168. |
| 43 |
232541414 |
Elastic Stop Nut M4 |
| 44 |
20037 |
Washer This part replaces M20037. |
| 45 |
M5446374 |
HINGE - Call your local BRP dealership |
| 46 |
36108 |
Rivet This part replaces M36083. |
| 47 |
293750070 |
Seat Retainer Cable This part replaces M546777. |
| 48 |
M40888 |
Screw |
| 49 |
M538856 |
Seat Belt |
| 50 |
M548824 |
Seat Belt Latch |
| 51 |
548834 |
Spring This part replaces M548834. |
| 52 |
M539455 |
Spring |
