| # | Part Number | Description | Qty | Status |
|---|
| - |
85090A2 |
SEAL KIT
|
1 |
|
| - |
99157A2 |
REPAIR KIT Water Pump
|
1 |
superseded
|
| 1 |
8669A42 |
GEAR HOUSING ASSEMBLY (15 IN. SHORT) (COMPLETE) (MERCURY)
|
1 |
disc.
|
| 1 |
8669A43 |
GEAR HOUSING ASSEMBLY (15 IN. SHORT) (COMPLETE) (MARINER)
|
1 |
disc.
|
| 1 |
8669A44 |
GEAR HOUSING ASSEMBLY (20 IN. LONG) (COMPLETE) (MERCURY)
|
1 |
disc.
|
| 1 |
8669A45 |
GEAR HOUSING ASSEMBLY (20 IN. LONG) (COMPLETE) (MARINER)
|
1 |
disc.
|
| 1 |
8669A21 |
GEAR HOUSING ASSEMBLY Basic-Black
|
1 |
superseded
|
| 1 |
8669A22 |
GEAR HOUSING ASSEMBLY Basic-Gray
|
1 |
disc.
|
| 10 |
67892A1 |
FITTING KIT Magnetic, Plug Fill/Drain
|
1 |
superseded
|
| 11 |
19183 |
WASHER Fiber
|
1 |
superseded
|
| 12 |
41134 |
SCREEN (STARBOARD)
|
1 |
|
| 13 |
400263 |
NUT (M5) SCREEN SCREW
|
1 |
disc.
|
| 14 |
98294A1 |
BEARING ASSEMBLY Roller
|
1 |
|
| 15 |
NSS |
NOT SOLD SEPARATE Cup-roller Bearing
|
1 |
|
| 16 |
984325 |
TRIM TAB
|
1 |
superseded
|
| 17 |
4000354 |
SCREW (M8 x 30)
|
1 |
|
| 18 |
8248324 |
SCREW (M6 x 16)
|
4 |
|
| 19 |
49908 |
SCREW (.250-28 x .750)
|
1 |
disc.
|
| 2 |
NSS |
NOT SOLD SEPARATE Sleeve
|
1 |
|
| 20 |
98302 |
GEAR Pinion
|
1 |
|
| 21 |
993261 |
GASKET
|
1 |
|
| 22 |
85083 |
FACE PLATE
|
1 |
|
| 23 |
8M0027721 |
WASHER
|
1 |
superseded
|
| 24 |
85119 |
KEY
|
1 |
superseded
|
| 25 |
850893 |
IMPELLER
|
1 |
superseded
|
| 26 |
8M0027721 |
WASHER
|
1 |
superseded
|
| 27 |
69202 |
O-RING
|
1 |
|
| 28 |
99157A1 |
PUMP ASSEMBLY Water
|
1 |
superseded
|
| 29 |
NSS |
NOT SOLD SEPARATE Insert
|
1 |
|
| 3 |
99325 |
SEAL
|
2 |
|
| 30 |
85090 |
SEAL
|
1 |
superseded
|
| 31 |
86203 |
O-RING
|
1 |
|
| 32 |
70132 |
WASHER (.323 x .563 x .063) Stainless Steel
|
1 |
superseded
|
| 33 |
853939 |
ROD Gear Shift (15 IN. SHORT MODELS)
|
1 |
disc.
|
| 33 |
853940 |
ROD Gear Shift (20 IN. LONG MODELS)
|
1 |
disc.
|
| 34 |
827024T |
DRIVESHAFT (15 IN. SHORT MODELS)
|
1 |
disc.
|
| 34 |
827025T |
DRIVESHAFT (20 IN. LONG MODELS)
|
1 |
disc.
|
| 35 |
85552 |
BOOT
|
1 |
superseded
|
| 36 |
93878 |
RETAINER
|
1 |
disc.
|
| 37 |
35276 |
O-RING (.734 x .139)
|
1 |
|
| 38 |
85594 |
O-RING (.239 x .174)
|
1 |
|
| 39 |
85562A2 |
SHIFT CAM
|
1 |
|
| 4 |
41326 |
BEARING Roller
|
1 |
|
| 40 |
85096 |
PIN Drive
|
1 |
|
| 5 |
85500 |
PIN Dowel (.187 x .530)
|
1 |
superseded
|
| 6 |
79953A2 |
SCREW KIT (.375-16 x .250)
|
1 |
superseded
|
| 7 |
19183 |
WASHER Fiber
|
1 |
superseded
|
| 8 |
41133 |
SCREEN Water Inlet Port
|
1 |
|
| 9 |
40031112 |
SCREW (M5 x 40)
|
1 |
|
