| # | Part Number | Description | Qty | Status |
|---|
| - |
819240A3 |
POWERHEAD ASSEMBLY
|
1 |
superseded
|
| 1 |
F681490 |
STOP Starter Pulley Interlock
|
1 |
disc.
|
| 10 |
816514 |
BEARING Spark Control
|
2 |
disc.
|
| 11 |
826590 |
STUD (.250-20 x 1.690) (.250-20 X 1.690)
|
1 |
disc.
|
| 12 |
824357 |
LEVER Neutral Speed Interlock
|
1 |
disc.
|
| 13 |
814101 |
NUT (.250-20) Stainless Steel
|
1 |
superseded
|
| 14 |
819159 |
ROD Interlock
|
1 |
disc.
|
| 15 |
819625 |
SCREW
|
1 |
disc.
|
| 16 |
F286685 |
CONNECTOR Gear Shift Rod
|
1 |
disc.
|
| 17 |
F98273 |
STUD
|
1 |
disc.
|
| 18 |
855621T |
LEVER Gear Shift
|
1 |
disc.
|
| 19 |
25319 |
PIN (.125 x 0.75 Inches)
|
1 |
|
| 2 |
F681003-1 |
ARM Starter Interlock
|
1 |
disc.
|
| 20 |
F286871T |
PIN Gear Shift Lever
|
1 |
disc.
|
| 21 |
26841 |
BUSHING
|
4 |
|
| 22 |
8193781 |
ROD Upper Gear Shift
|
1 |
disc.
|
| 23 |
F1976 |
SCREW (#10-24 x .500)
|
1 |
disc.
|
| 24 |
89302 |
WASHER (.203 x .406 x .040)
|
1 |
|
| 25 |
39627 |
SPRING
|
1 |
|
| 26 |
824994 |
SPRING Plate
|
1 |
|
| 27 |
850388 |
LINK Shift Lever
|
1 |
disc.
|
| 28 |
F8048 |
WASHER Bowed
|
1 |
disc.
|
| 29 |
26996 |
LOCKWASHER (#10) Stainless Steel
|
1 |
|
| 3 |
F8143 |
WASHER
|
2 |
disc.
|
| 30 |
F8058 |
LOCKWASHER Internal (#10)
|
1 |
disc.
|
| 31 |
850386 |
SHAFT Shift Handle
|
1 |
disc.
|
| 32 |
850387A1 |
LEVER ASSEMBLY Detent Cam
|
1 |
disc.
|
| 33 |
846345 |
STUD (#10-32 x .750)
|
1 |
|
| 34 |
25905 |
PIN
|
1 |
disc.
|
| 35 |
42813 |
SCREW (#10-32 X .380) (#10-32 X .380)
|
2 |
disc.
|
| 36 |
852545 |
HANDLE Shift
|
1 |
disc.
|
| 37 |
4002314 |
WASHER
|
1 |
|
| 38 |
15124 |
SCREW (#10-32 x .750)
|
1 |
|
| 4 |
48408 |
SCREW (#10-16 x .500)
|
2 |
|
| 5 |
F681263-1 |
LINK Starter Interlock
|
1 |
disc.
|
| 6 |
F681742 |
LEVER Intermediate Interlock
|
1 |
disc.
|
| 7 |
20110 |
NUT (#10-32)
|
2 |
|
| 8 |
F681424 |
SPRING Interlock Lever
|
1 |
disc.
|
| 9 |
F681134 |
STUD Interlock Lever
|
1 |
disc.
|
