Flywheel Coupler and Flywheel Housing
Parts (27)
| # | Part Number | Description | Qty | Status |
|---|---|---|---|---|
| 1 | 807456A2 |
КРЫШКА COVER |
1 | |
| 10 | 8M0098795 |
СОЕДИНИТЕЛЬНАЯ МУФТА В СБОРЕ Bravo COUPLER ASSEMBLY Bravo |
1 | |
| 11 | 863480 |
ВИНТ (0.375-16 x 1.125) Bravo SCREW (.375-16 x 1.125) Bravo |
6 | |
| 12 | 865657A03 |
КОРПУС В СБОРЕ Маховик Flywheel HOUSING ASSEMBLY Flywheel Flywheel |
1 | |
| 13 | 8M0103028 |
МОНТАЖНЫЙ КОМПЛЕКТ Резина MOUNT KIT Rubber |
1 | |
| 14 | 99322 |
ПРОСТАВКА SPACER |
2 | |
| 15 | 8M0215010 |
SCREW SCREW |
2 | |
| 16 | 35777 |
ШАЙБА (0.5156 x 1.375 x 0.125), алюминий WASHER (.5156 x 1.375 x .125) Aluminum |
2 | |
| 17 | 99299 |
ПРОСТАВКА (0.520 x 0.870 x 0.630) SPACER (.520 x .870 x .630) |
2 | |
| 18 | 861577 |
ШПИЛЬКА Двухсторонний, метрический (M10) STUD Double Ended Metric (M10) |
2 | |
| 19 | 892619A01 |
КОМПЛЕКТ ПРОКЛАДКИ Rear Engine Mount (Where Applicable) SHIM KIT Rear Engine Mount (Where Applicable) |
1 | |
| 2 | 76596 |
ВИНТ (0.250-20 x 1.250) SCREW (.250-20 x 1.250) |
2 | |
| 20 | 863332 |
ГАЙКА (0.500-20), алюминий NUT (.500-20) Aluminum |
2 | |
| 21 | 34567 |
ШАЙБА WASHER |
4 | |
| 22 | 40001197 |
ВИНТ (M10 x 35) SCREW (M10 x 35) |
3 | |
| 22 | 8M0157110 |
SCREW (M10 x 45) SCREW (M10 x 45) |
1 | |
| 23 | 40125100 |
ГАЙКА (M10) NUT (M10) |
2 | |
| 24 | 62826T06 |
КАБЕЛЬ В СБОРЕ Заземление (13.00"), черный CABLE ASSEMBLY Ground (13.00 Inches) Black |
2 | |
| 25 | 400248 |
СТОПОРНАЯ ШАЙБА (M10) LOCKWASHER (M10) |
2 | |
| 3 | 8M0133585 |
FLYWHEEL ASSEMBLY FLYWHEEL ASSEMBLY |
1 | |
| 4 | 43504 |
ШТИФТ Штифт Flywheel PIN Dowel Flywheel |
2 | |
| 5 | 8M0214958 |
SCREW (.437-20 x 1.00) SCREW (.437-20 x 1.00) |
6 | |
| 6 | 18643A5 |
СОЕДИНИТЕЛЬНАЯ МУФТА В СБОРЕ Alpha COUPLING ASSEMBLY Alpha |
1 | |
| 7 | 18644 |
УПОР Резина Alpha BUMPER Rubber Alpha |
3 | |
| 8 | 8M0204643 |
SCREW (.375-16 x 1.12) Alpha SCREW (.375-16 x 1.12) Alpha |
3 | |
| 9 | 13510 |
ШАЙБА Alpha WASHER Alpha |
3 | |
| NS | 8M0169589 |
FITTING Grease Alpha FITTING Grease Alpha |
1 |
