| # | Part Number | Description | Qty | Status |
|---|
| 1 |
8M0062666 |
HOSE (96.00 Inches Bulk) (Cut to Length)
|
1 |
|
| 1 |
8M0062653 |
HOSE (4 Inches) (Additional Inlet Applications)
|
A/R |
|
| 10 |
8M0109475 |
GASKET
|
1 |
|
| 11 |
8M2023904 |
HOSE
|
1 |
|
| 12 |
815504220 |
CLAMP Worm Gear
|
1 |
|
| 13 |
8M0074364 |
COVER Hose Clamp
|
A/R |
|
| 14 |
815504228 |
CLAMP Worm Gear Seacore
|
2 |
|
| 15 |
815504212 |
CLAMP Worm Gear Seacore
|
2 |
|
| 16 |
8M0103147 |
HOSE Flush Seacore
|
1 |
|
| 17 |
861406 |
SOCKET Seacore
|
1 |
|
| 18 |
858240 |
CAP Tethered Seacore
|
1 |
|
| 19 |
8M4501756 |
Y-FITTING Seacore
|
1 |
|
| 2 |
815504222 |
CLAMP Worm Gear (1.98 DIameter)
|
4 |
superseded
|
| 3 |
864727 |
FITTING Y, (3) 1-1/4 In. OD Hose Barbs (Additional Inlet Applications)
|
A/R |
|
| 4 |
865362 |
QUICK CONNECT
|
1 |
|
| 5 |
865324 |
QUICK CONNECT Bravo
|
1 |
|
| 6 |
8M6001459 |
CLAMP (45.5)
|
2 |
|
| 7 |
8M0109511 |
HOSE
|
1 |
|
| 8 |
73015 |
SCREW (.250-20 x 1.75)
|
2 |
|
| 9 |
8M0111791 |
HOUSING Water Inlet
|
1 |
|
