| # | Part Number | Description | Qty | Status |
|---|
| 1 |
8M0116637 |
Bracket Steering Pump
|
1 |
|
| 10 |
8M0082419 |
GASKET
|
2 |
|
| 11 |
8M0116534 |
PUMP ASSEMBLY Circulating
|
1 |
|
| 12 |
8M2021674 |
SCREW (.437-20 x 2.50)
|
1 |
|
| 13 |
8M0140918 |
SCREW (M8 x 1.25-16)
|
3 |
|
| 14 |
8M0095438 |
PULLEY
|
1 |
|
| 15 |
39131 |
LOCKWASHER (.437)
|
1 |
|
| 16 |
8M0109819 |
WASHER
|
1 |
|
| 17 |
8M0114815 |
HARMONIC DAMPER ASSEMBLY
|
1 |
|
| 18 |
4010618 |
SCREW (M6 x 18) Stainless Steel
|
1 |
|
| 19 |
879194363 |
SENSOR ASSEMBLY Crankshaft Position
|
1 |
|
| 2 |
88441430 |
SCREW (M10 x 30)
|
3 |
|
| 20 |
8M0145284 |
SCREW (M6 x 1-30)
|
6 |
|
| 21 |
8M0107029 |
COVER ASSEMBLY Timing Chain
|
1 |
|
| 22 |
8M6002623 |
SEAL Front
|
1 |
|
| 23 |
8M0123903 |
RELUCTOR WHEEL
|
1 |
|
| 24 |
8M0171911 |
TIMING CHAIN SET
|
1 |
|
| 25 |
NSS |
NOT SOLD SEPARATE Camshaft Sprocket
|
1 |
|
| 26 |
NSS |
NOT SOLD SEPARATE Crankshaft Sprocket
|
1 |
|
| 27 |
8M0043993 |
SCREW (.312-18 x.75)
|
3 |
|
| 28 |
8M0069696 |
GASKET
|
1 |
|
| 29 |
8M0220620 |
SERPENTINE BELT Raw Water Cooling
|
1 |
|
| 29 |
8M0220622 |
SERPENTINE BELT Fresh Water Cooling
|
1 |
|
| 3 |
865597T |
TENSIONER Belt
|
1 |
|
| 30 |
8M0095458 |
PULLEY Raw Water Cooling
|
1 |
|
| 30 |
8M0141494 |
PULLEY Fresh Water Cooling
|
1 |
|
| 31 |
4006731 |
SCREW (M6 x 16)
|
1 |
|
| 32 |
8M0233299 |
SENSOR ASSEMBLY Cam Position
|
1 |
|
| 4 |
8M0140384 |
SCREW (M8)
|
2 |
|
| 5 |
4010820 |
SCREW (M10 x 20) Hex Flange - Stainless Steel
|
1 |
|
| 6 |
865777 |
PULLEY
|
1 |
|
| 7 |
8M0140918 |
SCREW (M8 x 1.25-16)
|
4 |
|
| 8 |
8M0143753 |
STUD (M8 x 1.25)
|
1 |
|
| 9 |
8M0103817 |
SCREW (M8 x 60)
|
3 |
|
