| # | Part Number | Description | Qty | Status |
|---|
| - |
8M0114790 |
LONGBLOCK ASSEMBLY
|
1 |
|
| 1 |
8M0095933 |
COVER ASSEMBLY Rocker
|
2 |
|
| 10 |
8M0074362 |
VALVE Exhaust
|
6 |
|
| 11 |
8M0098000 |
VALVE Intake
|
6 |
|
| 12 |
NSS |
NOT SOLD SEPARATE Valve Seat (Intake)
|
6 |
|
| 13 |
NSS |
NOT SOLD SEPARATE Valve Seat (Exhaust)
|
6 |
|
| 14 |
8M6004772 |
VALVE SEAL ASSEMBLY
|
12 |
|
| 15 |
8M6002386 |
SPRING
|
12 |
|
| 16 |
8M6002848 |
KEY AND RETAINER ASSEMBLY
|
12 |
|
| 17 |
8M6002848 |
KEY AND RETAINER ASSEMBLY
|
12 |
|
| 18 |
8M6002071 |
PLUG Expansion
|
2 |
|
| 19 |
8M0074833 |
SCREW (M10 x 1.5 x 86)
|
14 |
|
| 2 |
8M0069613 |
GROMMET
|
6 |
|
| 20 |
8M0074832 |
SCREW (M10 x 1.5 x 49)
|
12 |
|
| 21 |
23784 |
PIN Dowel
|
4 |
|
| 22 |
8M6002404 |
GASKET
|
2 |
|
| 23 |
8M0083541 |
SCREW (M10 x 16) Port Lifting Eye
|
2 |
|
| 23 |
8M0083541 |
SCREW (M10 x 16) Starboard Lifting Eye
|
3 |
|
| 23 |
8M0083541 |
SCREW (M10 x 16) Alignment Eye
|
2 |
|
| 24 |
8M0095440 |
BRACKET Starboard Rear Lifting Eye
|
1 |
|
| 25 |
8M0091592 |
BRACKET Starboard Front Alignment Eye
|
1 |
|
| 26 |
97850T |
ELBOW 90 Degree
|
1 |
|
| 27 |
8M0188618 |
CLAMP Worm Gear (11-18 mm)
|
2 |
|
| 28 |
8M0086022 |
HOSE
|
1 |
|
| 29 |
8M2017060 |
VALVE PCV
|
1 |
|
| 3 |
8M0070507 |
GROMMET
|
2 |
|
| 30 |
8M0105232 |
HOSE (.375 ID x .62)
|
1 |
|
| 31 |
8M6002874 |
PUSH ROD
|
12 |
|
| 4 |
8M0069612 |
SCREW
|
6 |
|
| 5 |
8M0069616 |
SEAL
|
2 |
|
| 6 |
8M2024045 |
SCREW (M8 x 45)
|
12 |
|
| 7 |
8M0095926 |
ROCKER ARM
|
12 |
|
| 8 |
8M0068783 |
ALIGNMENT BAR
|
2 |
|
| 9 |
8M0116266 |
CYLINDER HEAD ASSEMBLY
|
2 |
|
| NS |
8M0091684 |
BRACKET Port Front Lifting Eye
|
1 |
|
