| # | Part Number | Description | Qty | Status |
|---|
| - |
824326A02 |
GASKET SET
|
1 |
|
| 1 |
860256A3 |
HOUSING ASSEMBLY Thermostat
|
1 |
|
| 10 |
861590A05 |
HOSE ASSEMBLY Thermostat Housing to Water Pump With Drain
|
1 |
|
| 11 |
862139 |
HOSE Thermostat Housing to Port Exhaust Manifold
|
1 |
|
| 12 |
862124 |
HOSE Thermostat Housing to Starboard Manifold
|
1 |
|
| 13 |
860088 |
BUSHING
|
1 |
superseded
|
| 14 |
37682 |
FITTING Elbow (45 Degree)
|
1 |
|
| 15 |
815504212 |
CLAMP Worm Gear
|
1 |
|
| 16 |
815504222 |
CLAMP Worm Gear (1.98 DIameter)
|
3 |
superseded
|
| 17 |
815504232 |
CLAMP Worm Gear (2.50 Diameter)
|
2 |
|
| 18 |
815504220 |
CLAMP Worm Gear
|
4 |
|
| 19 |
47715 |
CLIP
|
1 |
disc.
|
| 2 |
32803 |
PLUG Pipe (.375-18) Brass
|
2 |
superseded
|
| 20 |
29250 |
NUT (.312-24)
|
1 |
|
| 21 |
12552 |
LIFTING EYE
|
1 |
|
| 22 |
861554T01 |
COOLER
|
1 |
superseded
|
| 23 |
816585 |
SCREW (.312-18 x .875)
|
1 |
|
| 24 |
806608A02 |
PLUG ASSEMBLY (.500-13) Blue
|
1 |
superseded
|
| 25 |
26802 |
O-RING (.424 x .103)
|
1 |
|
| 3 |
806871 |
GASKET
|
1 |
superseded
|
| 4 |
530451 |
GASKET
|
1 |
|
| 5 |
807252T2 |
THERMOSTAT 71DegreeC (160 Degree F)
|
1 |
superseded
|
| 6 |
806922 |
SLEEVE
|
1 |
superseded
|
| 7 |
98508 |
SCREW (.375-16 x 3.00)
|
2 |
superseded
|
| 8 |
8062091 |
HOSE Thermostat Housing To Power Steering Oil Cooler
|
1 |
|
| 9 |
807661 |
HOSE
|
1 |
|
| NS |
8079923 |
COVER Hose Clamp End
|
AR |
superseded
|
