| # | Part Number | Description | Qty | Status |
|---|
| - |
852761A02 |
POWERHEAD ASSEMBLY
|
1 |
disc.
|
| - |
852783A1 |
GASKET SET Powerhead
|
1 |
disc.
|
| 1 |
852798A02 |
CRANKSHAFT
|
1 |
disc.
|
| 10 |
812495M |
BEARING
|
2 |
disc.
|
| 11 |
852803008 |
WASHER
|
4 |
disc.
|
| 12 |
82141M |
PIN Spring
|
1 |
disc.
|
| 13 |
84637M |
CIRCLIP
|
1 |
disc.
|
| 14 |
9580T |
PISTON (STANDARD)
|
2 |
disc.
|
| 14 |
9581M |
PISTON (1ST. O.S. 0.25MM)
|
AR |
disc.
|
| 14 |
9582M |
PISTON (2ND. O.S. 0.50MM)
|
AR |
disc.
|
| 15 |
15320T |
RING SET Piston (STANDARD)
|
2 |
disc.
|
| 15 |
18939T |
RING SET Piston (1ST. O.S. 0.25MM)
|
AR |
disc.
|
| 15 |
15322T |
RING SET Piston (2ND. O.S. 0.50MM)
|
AR |
disc.
|
| 16 |
825713 |
PIN Piston
|
2 |
disc.
|
| 17 |
82349M |
BEARING Needle
|
50 |
disc.
|
| 18 |
81823M |
WASHER
|
4 |
disc.
|
| 19 |
82343M |
CLIP
|
4 |
disc.
|
| 2 |
852800 |
BEARING
|
3 |
disc.
|
| 20 |
83936M |
SEAL Oil
|
1 |
disc.
|
| 21 |
852802 |
SPACER
|
2 |
disc.
|
| 22 |
852803 |
WASHER
|
1 |
disc.
|
| 23 |
852795 |
HOUSING
|
1 |
disc.
|
| 24 |
852797 |
SEAL Oil
|
1 |
disc.
|
| 25 |
852796 |
O-RING
|
1 |
disc.
|
| 26 |
96606001 |
SEAL Oil
|
2 |
disc.
|
| 27 |
852797001 |
SEAL Oil
|
1 |
disc.
|
| 28 |
826957M |
BOLT
|
1 |
disc.
|
| 29 |
82214M |
WASHER
|
1 |
disc.
|
| 3 |
827192M |
CRANK
|
1 |
disc.
|
| 30 |
81914M |
KEY
|
1 |
superseded
|
| 4 |
852799 |
CRANK
|
1 |
disc.
|
| 5 |
8527991 |
CRANK
|
1 |
disc.
|
| 6 |
8527992 |
CRANK
|
1 |
disc.
|
| 7 |
852801001 |
SEAL
|
1 |
disc.
|
| 8 |
84625M |
PIN
|
2 |
disc.
|
| 9 |
812494M |
CONNECTING ROD
|
2 |
disc.
|
