| # | Part Number | Description | Qty | Status |
|---|
| - |
8M0146128 |
GEAR HOUSING ASSEMBLY (Camber) (Standard Long) (1.75) (Sport Master)
|
1 |
superseded
|
| - |
8M0205802 |
REPAIR KIT Water Pump Mercury
|
1 |
|
| - |
8M0205803 |
REPAIR KIT Water Pump QuickSilver
|
1 |
|
| - |
8M0142979 |
SEAL KIT
|
1 |
|
| 1 |
8M0168313 |
GEAR HOUSING ASSEMBLY Basic Sport Master Camber Skeg Silver
|
1 |
|
| 10 |
8M0063268 |
SHIM SET
|
1 |
|
| 11 |
8M0146553 |
BEARING ASSEMBLY Cup/Cone
|
1 |
|
| 12 |
8M0063267 |
SHIM SET
|
1 |
|
| 13 |
8M0146566 |
BEARING ASSEMBLY Cup/Cone
|
1 |
|
| 14 |
8245191 |
RETAINER
|
1 |
|
| 15 |
8M0142854 |
O-RING (2.175 x .103)
|
1 |
|
| 16 |
880719 |
RING Retaining
|
1 |
|
| 17 |
8M0046297 |
OIL SEAL CARRIER ASSEMBLY
|
1 |
|
| 18 |
8M0146938 |
GASKET Water Pump Base
|
1 |
|
| 19 |
8M0174560 |
COVER Gearcase Housing
|
1 |
|
| 2 |
847635001 |
ANODE
|
1 |
|
| 20 |
8M0142616 |
GASKET Face Plate to Gearcase
|
1 |
|
| 21 |
8172771 |
GASKET Water Pump, Upper
|
1 |
|
| 22 |
8M0204723 |
KEY
|
1 |
|
| 23 |
43026Q02 |
IMPELLER
|
1 |
|
| 24 |
817275A1 |
HOUSING KIT Water Pump
|
1 |
|
| 25 |
8M0204645 |
O-RING (.796 x .139)
|
1 |
|
| 26 |
8M0142851 |
VRING Face Seal
|
1 |
|
| 27 |
8M0142435 |
COUPLING Water Pump
|
1 |
|
| 28 |
8M0204706 |
SCREW M6 x 20 Hex
|
4 |
|
| 29 |
8M0142866 |
RING Retaining
|
1 |
|
| 3 |
8M0036047 |
SCREW (.375 x .62)
|
2 |
|
| 30 |
8M0164968 |
SHIFT SHAFT Long
|
1 |
|
| 31 |
8M0164967 |
BUSHING Shift Shaft
|
1 |
|
| 32 |
8M0046563 |
RING Retaining
|
1 |
|
| 33 |
8M0142860 |
O-RING .706 x .097
|
1 |
|
| 34 |
8M0204708 |
SEAL Oil
|
1 |
|
| 35 |
77674 |
WASHER (.35 x .75 x .12)
|
1 |
|
| 36 |
43044 |
PIN Dowel - Without Hole (.375 x .625)
|
2 |
|
| 37 |
8M0142659 |
SEAL Formed, Actuator
|
2 |
|
| 4 |
841388 |
WASHER (.410 x .810 x .050) Stainless Steel
|
2 |
|
| 5 |
NSS |
NOT SOLD SEPARATE Pinion
|
1 |
|
| 6 |
8M0046636 |
NUT
|
1 |
|
| 7 |
8M0062703 |
WASHER
|
1 |
|
| 8 |
8M0045676 |
BEARING Roller
|
1 |
|
| 9 |
8M0149608 |
DRIVESHAFT ASSEMBLY Long
|
1 |
|
