| # | Part Number | Description | Qty | Status |
|---|
| 1 |
8M0142775 |
HOUSING Driveshaft, Black
|
1 |
|
| 1 |
8M0145916 |
HOUSING Driveshaft, Silver
|
1 |
superseded
|
| 10 |
8M0142978 |
SEAL ACTUATOR
|
1 |
|
| 11 |
8M0142714 |
FITTING
|
1 |
|
| 12 |
8M0155119 |
FITTING Legris
|
1 |
|
| 13 |
8M0142715 |
BRACKET Bib Mount
|
2 |
|
| 14 |
8M0142716 |
INSERT
|
2 |
|
| 15 |
40011106 |
SCREW (M5 x 13) Stainless Steel
|
2 |
|
| 16 |
8M0008031 |
STUD (M12 x 1.75 x 52) Long
|
5 |
|
| 16 |
8M0142781 |
STUD (M12 x 179) XLong
|
5/AR |
|
| 16 |
8M0142788 |
STUD (M12 x 306) XXLong
|
5/AR |
|
| 17 |
856982 |
WASHER (.500 x .810 x .090) Stainless Steel
|
5/AR |
|
| 18 |
896895 |
NUT (M12)
|
5/AR |
|
| 2 |
8M0142713 |
CAP Chap Support
|
4 |
|
| 3 |
8M0112869 |
OIL PLUG ASSEMBLY
|
1 |
|
| 4 |
85045 |
O-RING (.551 x .070)
|
1 |
|
| 5 |
863006 |
O-RING (10.82 x 1.78)
|
1 |
|
| 6 |
8M0036228 |
O-RING (8.1 X 1.6)
|
1 |
|
| 7 |
8M0142829 |
SCREW (M6 x 20)
|
4 |
|
| 8 |
8M0204944 |
SHIFT ACTUATOR
|
1 |
|
| 9 |
8M0147857 |
SHAFT Coupling
|
1 |
|
