| # | Part Number | Description | Qty | Status |
|---|
| 1 |
8M0161581 |
SWIVEL BRACKET Black
|
1 |
|
| 1 |
8M0161582 |
SWIVEL BRACKET Silver
|
1 |
|
| 10 |
852368 |
SCREW (#10-24 x .750)
|
2 |
|
| 11 |
26996 |
LOCKWASHER (#10) Stainless Steel
|
2 |
|
| 12 |
89302 |
WASHER (.203 x .406 x .040)
|
2 |
|
| 13 |
8M0045383 |
STRIKER PLATE
|
2 |
|
| 14 |
58643 |
LOCKWASHER (.375)
|
2 |
|
| 15 |
73286 |
SCREW (.250-20 x .500) Stainless Steel
|
1 |
|
| 16 |
46335 |
NUT (.375-24)
|
2 |
|
| 17 |
8M0220988 |
BUSHING Swivel Tube Pivot
|
1 |
|
| 18 |
67684 |
RING Retaining
|
1 |
|
| 19 |
8M0142797 |
YOKE
|
1 |
|
| 2 |
8M0142803 |
STEERING ARM Black
|
1 |
|
| 2 |
8M0146931 |
STEERING ARM Silver
|
1 |
|
| 20 |
8M0142798 |
STUD (M14 x 146)
|
2 |
|
| 21 |
8M0142796 |
MOUNT Snubber
|
1 |
|
| 22 |
847541 |
WASHER
|
4 |
|
| 23 |
81893435 |
SCREW (M8 x 35)
|
4 |
|
| 24 |
8M0142802 |
COVER Lower Mount
|
2 |
|
| 25 |
813771003 |
MOUNT Lower 150R
|
2 |
|
| 25 |
8M0149561 |
MOUNT LOWER Solid 200R
|
2 |
|
| 26 |
8M0142795 |
WASHER (1.25 x 19)
|
2 |
|
| 27 |
815432 |
WASHER (.562 x 2.00 x .125)
|
2 |
|
| 28 |
896602 |
NUT (M14)
|
2 |
|
| 29 |
8M0142799 |
CABLE ASSEMBLY
|
1 |
|
| 3 |
816432 |
THRUST WASHER
|
2 |
|
| 30 |
8M0160545 |
CABLE ASSEMBLY 10 IN
|
1 |
|
| 31 |
825190 |
WASHER
|
1 |
|
| 4 |
8M0034870 |
SEAL Swivel Tube
|
2 |
|
| 5 |
88750 |
WASHER Wave (1.62 x 1.05)
|
2 |
|
| 6 |
893709 |
PIN
|
1 |
|
| 7 |
830899 |
SPRING Tension
|
1 |
|
| 8 |
8M0169589 |
FITTING Grease
|
2 |
|
| 9 |
8M0142805 |
TRIM POSITION SENSOR
|
1 |
|
