| # | Part Number | Description | Qty | Status |
|---|---|---|---|---|
| - | 92729A49 | HARDWARE KIT Transom Mounting | 1 | |
| - | 8M0226901 | CONVERSION KIT Remote Control Models to Tiller Models | 1 | |
| 1 | 815030T06 | CLAMP BRACKET Starboard | 1 | |
| 1 | 815031T06 | CLAMP BRACKET Port | 1 | |
| 10 | 855544015 | SCREW | 2 | |
| 11 | 813028004 | SPRING | 2 | |
| 12 | 815096001 | KNOB | 2 | |
| 13 | 12869 | DECAL Tilt Position | 1 | |
| 14 | 128671 | DECAL Lower Tilt Limit | 1 | |
| 15 | 895165 | TILT LOCK | 1 | |
| 16 | 8M0176078 | CLAMP SCREW KIT | 2 | |
| 17 | 95379 | PAD | 2 | disc. |
| 18 | 815082002 | HANDLE Carrying | 1 | |
| 2 | 898101191 | TILT TUBE ASSEMBLY | 1 | |
| 3 | 853722029 | NUT Nylon | 1 | |
| 4 | 95375001 | WASHER | 2 | |
| 5 | 895163002 | PLATE | 1 | |
| 6 | 85372214 | CAP NUT | 2 | |
| 7 | 803771001 | SPACER | 1 | |
| 8 | 8M0102279 | BOLT | 2 | |
| 9 | 895164 | CAM | 1 |
