| # | Part Number | Description | Qty | Status |
|---|
| - |
8M0227954 |
CONVERSION KIT Tiller Handle Models to Remote Control Models
|
1 |
|
| 1 |
8M0223414 |
THROTTLE LEVER
|
1 |
|
| 10 |
8M0223420 |
LEVER
|
1 |
|
| 11 |
803768003 |
SHIFT DETENT Standard
|
1 |
|
| 11 |
802971002 |
SHIFT DETENT Command Thrust
|
1 |
|
| 12 |
8M0223419 |
SHIFT LEVER SHAFT
|
1 |
|
| 13 |
895157 |
BRACKET
|
1 |
|
| 14 |
8M0230557 |
BRACKET Stop
|
1 |
|
| 15 |
8M0155407 |
SPRING Shift Detent
|
2 |
|
| 16 |
8M0135810 |
SHIFT DETENT Supporter
|
1 |
|
| 17 |
855544014 |
SCREW
|
3 |
|
| 18 |
16335 |
WASHER
|
3 |
|
| 19 |
16219003 |
SEAL
|
1 |
|
| 2 |
8M0223415 |
COLLAR
|
1 |
|
| 20 |
8M0223423 |
SHIFT LEVER ROD
|
1 |
|
| 21 |
898101218 |
WASHER Plastic
|
2 |
|
| 22 |
161404 |
WASHER
|
1 |
|
| 23 |
16221 |
WAVE WASHER
|
1 |
|
| 24 |
8M0223422 |
SHIFT LEVER
|
1 |
|
| 25 |
16220 |
BUSHING
|
1 |
|
| 26 |
16219 |
SEAL
|
1 |
|
| 27 |
17640001 |
SHOULDER SCREW
|
1 |
|
| 28 |
803766003 |
SHIFT SHAFT Upper
|
1 |
superseded
|
| 29 |
8M0223421 |
SHIFT ARM
|
1 |
|
| 3 |
953921 |
WASHER Stainless Steel
|
1 |
|
| 30 |
804906001 |
LOCK Reverse
|
1 |
|
| 31 |
803767002 |
COUPLER
|
1 |
|
| 32 |
16827 |
SCREW
|
1 |
|
| 4 |
8M0174563 |
SHOULDER BOLT
|
1 |
|
| 5 |
8M0223416 |
THROTTLE ROD Remote Control
|
1 |
|
| 6 |
8M0223418 |
BRACKET Throttle Wire
|
1 |
|
| 7 |
8M0155474 |
SCREW
|
2 |
|
| 7 |
8M0155474 |
SCREW
|
5 |
|
| 8 |
8M0186817 |
WASHER
|
2 |
|
| 9 |
8M0021224 |
CLIP Bow-Tie
|
4 |
|
