| # | Part Number | Description | Qty | Status |
|---|
| 1 |
8M0223405 |
RECOIL STARTER ASSEMBLY
|
1 |
|
| 10 |
812637001 |
BOLT
|
1 |
|
| 11 |
812638001 |
FRICTION PLATE
|
1 |
|
| 12 |
8M0110704 |
ROPE
|
1 |
|
| 13 |
812640002 |
HANDLE Starter Rope
|
1 |
|
| 14 |
8M0084137 |
ROPE ANCHOR
|
1 |
|
| 15 |
8M0138706 |
SEAL Starter
|
1 |
|
| 16 |
804031001 |
INTERLOCK Starter
|
1 |
|
| 17 |
8555449 |
SCREW ASSEMBLY
|
1 |
|
| 18 |
895130 |
COLLAR
|
1 |
|
| 19 |
812645007 |
SPRING
|
1 |
|
| 2 |
8M0223407 |
ROPE GUIDE
|
2 |
|
| 20 |
803721003 |
CAM
|
1 |
|
| 21 |
898101627 |
LEVER Starter Lock
|
1 |
|
| 22 |
898101628 |
SPRING
|
1 |
|
| 23 |
16826 |
WASHER Stainless Steel
|
1 |
|
| 24 |
855544021 |
SCREW (M6 x 25 MM)
|
1 |
|
| 25 |
855545004 |
COLLAR
|
1 |
|
| 26 |
803719 |
SHAFT Starter
|
1 |
|
| 3 |
895128 |
WAVE WASHER
|
1 |
|
| 4 |
804024T07 |
SPRING Starter
|
1 |
|
| 5 |
895129 |
HOUSING Spring
|
1 |
|
| 6 |
803717001 |
REEL
|
1 |
|
| 7 |
812634003 |
SPRING Return
|
2 |
|
| 8 |
812635002 |
RATCHET
|
2 |
|
| 9 |
812636001 |
SPRING
|
1 |
|
