| # | Part Number | Description | Qty | Status |
|---|
| - |
8M0210573 |
GEAR HOUSING ASSEMBLY (Standard, Long) Graphite Grey 1.60
|
1 |
superseded
|
| - |
8M0210574 |
GEAR HOUSING ASSEMBLY (Standard, X-Long) Graphite Grey 1.60
|
1 |
superseded
|
| - |
8M0210575 |
GEAR HOUSING ASSEMBLY (Standard, XX-Long) Graphite Grey 1.60
|
1 |
superseded
|
| - |
8M0210576 |
GEAR HOUSING ASSEMBLY (Standard, XXX-Long) Graphite Grey 1.60
|
1 |
superseded
|
| - |
8M0210581 |
GEAR HOUSING ASSEMBLY (Standard, Long) Cold Fusion White 1.60
|
1 |
superseded
|
| - |
8M0210583 |
GEAR HOUSING ASSEMBLY (Standard, X-Long) Cold Fusion White 1.60
|
1 |
superseded
|
| - |
8M0210585 |
GEAR HOUSING ASSEMBLY (Standard, XX-Long) Cold Fusion White 1.60
|
1 |
superseded
|
| - |
8M0210587 |
GEAR HOUSING ASSEMBLY (Standard, XXX-Long) Cold Fusion White 1.60
|
1 |
|
| 1 |
8M0219304 |
GEAR HOUSING ASSEMBLY Basic, Standard, Graphite Grey
|
1 |
|
| 1 |
8M0219305 |
GEAR HOUSING ASSEMBLY Basic, Standard, Cold Fusion White
|
1 |
|
| 10 |
8M0210515 |
BUSHING Shift
|
1 |
|
| 11 |
8M0232475 |
SPOOL ASSEMBLY
|
1 |
superseded
|
| 12 |
8M0232465 |
SHIM SET
|
1 |
|
| 13 |
8M0210527 |
BEARING
|
1 |
|
| 14 |
8M0200142 |
RETAINING Ring
|
1 |
|
| 15 |
8M0200143 |
WASHER Thrust
|
1 |
|
| 16 |
8M0200144 |
BEARING Roller Taper (Cup/Cone)
|
1 |
|
| 17 |
8M0232459 |
GEAR SET
|
1 |
|
| 18 |
8M0219228 |
SPRING Clutch Pin
|
1 |
|
| 19 |
8M0239527 |
PIN Cross
|
1 |
|
| 2 |
8M0210511 |
PLUG Torpedo
|
1 |
|
| 20 |
8M0200147 |
CLUTCH
|
1 |
|
| 21 |
8M0232468 |
SHIM SET
|
1 |
|
| 22 |
8M0220160 |
PROPELLER SHAFT
|
1 |
|
| 23 |
8M0210544 |
BEARNG CARRIER ASSEMBLY
|
1 |
|
| 24 |
NSS |
NOT SOLD SEPARATE Gear Set
|
1 |
|
| 25 |
8M0219431 |
RING Thrust
|
1 |
|
| 26 |
8M0200161 |
BEARING ASSEMBLY Roller Taper (Cup/Cone)
|
2 |
|
| 27 |
8M0219432 |
SPACER Cup
|
1 |
|
| 28 |
8M0200163 |
SPACER Cone
|
1 |
|
| 29 |
8M0219433 |
BEARING-NEEDLE Needle
|
1 |
|
| 3 |
8M0210514 |
QUAD RING
|
1 |
|
| 30 |
8M0219434 |
RETAINING RING
|
1 |
|
| 31 |
8M0200164 |
NUT Lock, 2.625-16
|
1 |
|
| 32 |
8M0066130 |
SCREW- HALF DOG POINT SET
|
1 |
|
| 33 |
8M0219435 |
BEARING Cup/Cone
|
1 |
|
| 34 |
8M0200154 |
SEAL Oil
|
1 |
|
| 35 |
8M0219436 |
O-RING
|
1 |
|
| 36 |
38489 |
PIN Roll
|
2 |
|
| 37 |
8M0210545 |
SPACER Bearing
|
1 |
|
| 38 |
8M0206007 |
SHIM SET 1.505 x 1.745 (.014 - .044)
|
1 |
|
| 39 |
8M0215074 |
DOWEL PIN
|
1 |
|
| 4 |
8M0050602 |
MAGNET
|
1 |
|
| 40 |
8M0204693 |
SEAL Drain Plug
|
2 |
|
| 41 |
8M0071653 |
SCREW Special, .375-16 UNC
|
2 |
|
| 42 |
8M0210542 |
WASHER-TAB Tab
|
1 |
|
| 43 |
8M0210543 |
RETAINER NUT
|
1 |
|
| 5 |
892073002 |
SHOULDER SCREW (M6)
|
1 |
superseded
|
| 6 |
8M0220902 |
NOSE CAP 4 Holes
|
1 |
|
| 6 |
8M0220903 |
NOSE CAP 14 Holes
|
1 |
disc.
|
| 7 |
45257 |
O-RING (1.489 x .070)
|
1 |
|
| 8 |
8M0210513 |
RETAINER
|
1 |
|
| 9 |
8M0046215 |
CRANK, Shifter 1/4 Pivot Pin
|
1 |
superseded
|
