| # | Part Number | Description | Qty | Status |
|---|---|---|---|---|
| - | 8M0210470 |
LONG BLOCK ASSEMBLY LONG BLOCK ASSEMBLY |
1 | superseded |
| - | 8M0210444 |
GASKET SET Longblock GASKET SET Longblock |
1 | |
| 1 | 8M0210477 |
THERMOSTAT ASSEMBLY THERMOSTAT ASSEMBLY |
1 | |
| 10 | 8M0187145 |
CLAMP CLAMP |
1 | |
| 11 | 8M0142500 |
РУКАВ Выпуск термостата HOSE Thermostat Outlet |
1 | |
| 12 | 816311T |
ЛЕНТОЧНЫЙ ХОМУТ (8.00") TIE STRAP (8.00 Inches) |
22 | |
| 13 | 8M0162444 |
HOSE Supercharger Water Out HOSE Supercharger Water Out |
1 | |
| 14 | 8M0162443 |
HOSE Oil Cooler Water Out HOSE Oil Cooler Water Out |
1 | |
| 15 | 8M0210500 |
HOSE ASSEMBLY Starboard HOSE ASSEMBLY Starboard |
1 | superseded |
| 16 | 8M0142523 |
УПЛОТНИТЕЛЬНОЕ КОЛЬЦО (В.Д. 8,1 ММ X 1,6 ММ) O-RING (8.1 MM ID X 1.6MM) |
1 | |
| 17 | 8M0162448 |
FITTING Water Inlet FITTING Water Inlet |
1 | superseded |
| 18 | 86614 |
УПЛОТНИТЕЛЬНОЕ КОЛЬЦО (1.049 x 0.103) O-RING (1.049 x .103) |
1 | |
| 19 | 8M0162442 |
HOSE Spayer HOSE Spayer |
1 | superseded |
| 2 | 8M0214923 |
O-RING (1.98 x 1.39) O-RING (1.98 x 1.39) |
1 | |
| 20 | 888988011 |
ЗАЖИМ (38,1 ММ) CLAMP (38.1 MM) |
2 | |
| 21 | 8M0172177 |
HOSE HOSE |
1 | |
| 22 | 8M0162441 |
GROMMET Water Lines Starboard GROMMET Water Lines Starboard |
1 | |
| 23 | 8M0142509 |
ФИТИНГ Соединитель FITTING Connector |
1 | |
| 24 | 8M0142501 |
УПЛОТНИТЕЛЬНОЕ КОЛЬЦО GROMMET |
2 | |
| 25 | 8M0142506 |
ФИТИНГ Соединитель FITTING Connector |
1 | |
| 26 | 8M0210499 |
HOSE ASSEMBLY Water Inlet Starboard HOSE ASSEMBLY Water Inlet Starboard |
1 | |
| 27 | 8M0210506 |
HOSE ASSEMBLY Supercharger to Poppet HOSE ASSEMBLY Supercharger to Poppet |
1 | |
| 28 | 884546 |
УПЛОТНИТЕЛЬНОЕ КОЛЬЦО GROMMET |
1 | |
| 29 | 8M0210507 |
HOSE ASSEMBLY Oil Cooler to Poppet HOSE ASSEMBLY Oil Cooler to Poppet |
1 | |
| 3 | 8M0103806 |
ВИНТ (M6 x 20 мм), нержавеющая сталь SCREW (M6 x 20 MM) Stainless Steel |
8 | |
| 30 | 884546 |
УПЛОТНИТЕЛЬНОЕ КОЛЬЦО GROMMET |
1 | |
| 31 | 892073002 |
ВИНТ С БУРТИКОМ (M6) SHOULDER SCREW (M6) |
6 | superseded |
| 32 | 8M0210493 |
BRACKET Poppet BRACKET Poppet |
1 | |
| 33 | 8M0210508 |
HOSE Oil Cooler, Water in HOSE Oil Cooler, Water in |
1 | |
| 34 | 8M0161404 |
POPPET VALVE ASSEMBLY POPPET VALVE ASSEMBLY |
2 | |
| 35 | 8M0210437 |
HOSE XXX-Long Only HOSE XXX-Long Only |
1 | |
| 36 | 8M0210503 |
HOSE ASSEMBLY Poppet to Sprayer Starboard HOSE ASSEMBLY Poppet to Sprayer Starboard |
1 | |
| 37 | 8M0162402 |
HOSE ASSEMBLY Water Drain HOSE ASSEMBLY Water Drain |
1 | |
| 38 | 8M0210461 |
HOSE Poppet to Sprayer Port HOSE Poppet to Sprayer Port |
1 | |
| 39 | 8M0142518 |
ШЛАНГ В СБОРЕ Cylinder Head Drain HOSE ASSEMBLY Cylinder Head Drain |
1 | |
| 4 | 8M0142494 |
ФИТИНГ FITTING |
1 | |
| 40 | 884546 |
УПЛОТНИТЕЛЬНОЕ КОЛЬЦО GROMMET |
1 | |
| 41 | 8M0162403 |
HOSE ASSEMBLY Water Drain HOSE ASSEMBLY Water Drain |
1 | |
| 42 | 8M0162425 |
HOSE ASSEMBLY Water Inlet, Port HOSE ASSEMBLY Water Inlet, Port |
1 | |
| 43 | 8M0162427 |
GROMMET Water Lines, Port GROMMET Water Lines, Port |
1 | |
| 44 | 8M0210501 |
HOSE ASSEMBLY Inlet to Oil Cooler Port HOSE ASSEMBLY Inlet to Oil Cooler Port |
1 | superseded |
| 45 | 8M0142523 |
УПЛОТНИТЕЛЬНОЕ КОЛЬЦО (В.Д. 8,1 ММ X 1,6 ММ) O-RING (8.1 MM ID X 1.6MM) |
1 | |
| 46 | 8M0142510 |
ФИТИНГ FITTING |
2 | |
| 47 | 8M0204650 |
O-RING O-RING |
2 | |
| 48 | 8M0142505 |
РУКАВ Water Inlet to Head Port HOSE Water Inlet to Head Port |
1 | |
| 49 | 8M0142504 |
РУКАВ Water Inlet to Head Starboard HOSE Water Inlet to Head Starboard |
1 | |
| 5 | 35480 |
УПЛОТНИТЕЛЬНОЕ КОЛЬЦО (1.237 x 0.103) O-RING (1.237 x .103) |
1 | |
| 50 | 8M0142507 |
Y-ОБРАЗНЫЙ ФИТИНГ YFITTING |
1 | |
| 51 | 26317 |
УПЛОТНИТЕЛЬНОЕ КОЛЬЦО O-RING (1.109 x .139) |
1 | |
| 52 | 8M0161403 |
HOSE ASSEMBLY FLUSH HOSE ASSEMBLY FLUSH |
1 | |
| 53 | 899145 |
ЗАЖИМ Ленточный хомут CLIP Tie Strap |
1 | |
| 54 | 8M0210509 |
HOSE Oil Cooler, Water Out HOSE Oil Cooler, Water Out |
1 | |
| 55 | 8M0142585 |
ЗАЖИМ CLAMP (16.2 x 7 x .6 MM) |
2 | |
| 56 | 8M0210502 |
HOSE Supercharger, Water In HOSE Supercharger, Water In |
1 | |
| 57 | 8M0218504 |
GROMMET GROMMET |
1 | |
| 58 | 8M0231823 |
RESTRICTOR KIT RESTRICTOR KIT |
1 | |
| 59 | 8M0028753 |
ЗАЖИМ Oetiker (диаметр 31,6) CLAMP Oetiker (31.6 Diameter) |
1 | |
| 6 | 8M0028753 |
ЗАЖИМ Oetiker (диаметр 31,6) CLAMP Oetiker (31.6 Diameter) |
6 | |
| 7 | 8M0142503 |
РУКАВ Охлаждение HOSE Cooling |
1 | |
| 8 | 8M0142516 |
ФИТИНГ Зазубренный FITTING Barbed |
1 | |
| 9 | 8M0142517 |
УПЛОТНИТЕЛЬНОЕ КОЛЬЦО (В.Д. 23,6 ММ X 2,9 ММ) O-RING (23.6 MM ID X 2.9 MM) |
1 |
