| # | Part Number | Description | Qty | Status |
|---|
| - |
8M0134483 |
GEAR HOUSING ASSEMBLY Complete, Short
|
1 |
superseded
|
| - |
8M0134484 |
GEAR HOUSING ASSEMBLY Complete, Long
|
1 |
superseded
|
| - |
8M0134485 |
GEAR HOUSING ASSEMBLY Complete, X-Long
|
1 |
superseded
|
| - |
8M0135820 |
GEARCASE SEAL KIT
|
1 |
|
| - |
8M0135821 |
COMPLETE WATER PUMP KIT Repair
|
1 |
|
| - |
8M0137849 |
WATER PUMP KIT Chrome
|
1 |
|
| 1 |
8M0135572 |
GEAR HOUSING Basic
|
1 |
|
| 10 |
803742 |
WASHER
|
1 |
|
| 11 |
8M0134490 |
GEAR Reverse
|
1 |
|
| 12 |
8M0087846 |
O-RING
|
1 |
|
| 13 |
8M0134487 |
BEARING Ball
|
1 |
|
| 14 |
8M0138531 |
BUSHING
|
1 |
disc.
|
| 15 |
8M0134486 |
BEARING CARRIER ASSY
|
1 |
superseded
|
| 16 |
8M0137345 |
BOLT
|
2 |
superseded
|
| 17 |
161622 |
SEAL Oil
|
1 |
|
| 18 |
897752A11 |
BLACK MAX PROPELLER 9.25 x 10
|
1 |
|
| 18 |
897750A11 |
BLACK MAX PROPELLER 9.25 x 9
|
1 |
|
| 18 |
812948A10 |
BLACK MAX PROPELLER 10 x 7
|
1 |
|
| 18 |
8M0228896 |
PROPELLER ASSEMBLY 8.7 x 5
|
1 |
|
| 19 |
8M0137844 |
PROP HARDWARE KIT
|
1 |
|
| 2 |
879147T60 |
BEARING Ball
|
1 |
|
| 20 |
803743 |
THRUST HOLDER
|
1 |
superseded
|
| 21 |
161402 |
WASHER
|
1 |
|
| 22 |
161471 |
PROP NUT
|
1 |
|
| 23 |
8150264 |
COTTER PIN
|
1 |
|
| 3 |
8M0134488 |
GEAR Forward
|
1 |
superseded
|
| 4 |
8M0137346 |
PUSH ROD
|
1 |
|
| 5 |
803746 |
SPRING
|
1 |
|
| 6 |
879147T93 |
CLUTCH
|
1 |
|
| 7 |
160851 |
PIN
|
1 |
|
| 8 |
176672 |
SPRING
|
1 |
|
| 9 |
8M0134491 |
SHAFT Propeller
|
1 |
superseded
|
