| # | Part Number | Description | Qty | Status |
|---|
| - |
8M0140877 |
CO PILOT KIT
|
1 |
|
| - |
8M0134438 |
POWERHEAD GASKET SET
|
1 |
|
| 1 |
8M0134662 |
SWIVEL BRACKET ASSEMBLY Short
|
1 |
|
| 1 |
8M0134663 |
SWIVEL BRACKET ASSEMBLY Long and XLong
|
1 |
|
| 10 |
8M0140496 |
PLATE
|
1 |
superseded
|
| 11 |
8M0106739 |
BOLT
|
2 |
|
| 12 |
8M0134504 |
LOCK Reverse
|
1 |
|
| 13 |
8M0135840 |
SPRING Reverse Lock
|
2 |
|
| 14 |
8M0135839 |
LINK Reverse Lock
|
1 |
|
| 15 |
8037841 |
ROD Reverse Lock
|
1 |
|
| 16 |
8150261 |
COTTER PIN
|
2 |
|
| 17 |
8037461 |
SPRING
|
1 |
|
| 18 |
8M0135837 |
ARM Reverse Lock
|
1 |
|
| 19 |
8M0135838 |
SHAFT Reverse Lock
|
1 |
|
| 2 |
8M0137356 |
PIN
|
2 |
|
| 20 |
160572 |
E RING
|
2 |
|
| 21 |
8M0135836 |
LEVER Reverse Lock
|
1 |
superseded
|
| 22 |
898103106 |
GRIP
|
1 |
|
| 23 |
8M0051399 |
STOPPER
|
1 |
|
| 24 |
803790001 |
BOLT Shoulder
|
1 |
|
| 25 |
16192 |
WASHER
|
1 |
|
| 26 |
898103107 |
BUSHING
|
1 |
|
| 27 |
953925 |
WASHER
|
1 |
|
| 28 |
953921 |
WASHER Stainless Steel
|
1 |
|
| 29 |
8M0137358 |
BOLT
|
1 |
|
| 3 |
824969 |
FITTING Grease
|
3 |
|
| 30 |
168231 |
O-RING
|
1 |
|
| 31 |
895173 |
DISC
|
2 |
superseded
|
| 32 |
8M0137359 |
WASHER Spacer
|
1 |
superseded
|
| 33 |
8M0135834 |
PLATE
|
1 |
|
| 34 |
8230427 |
BOLT ASSEMBLY (M6 x 12)
|
2 |
|
| 35 |
8M0135833 |
HANDLE
|
1 |
|
| 36 |
895146001 |
WASHER
|
1 |
|
| 37 |
8M0137357 |
WASHER
|
1 |
|
| 38 |
95374001 |
NUT Nylon
|
1 |
|
| 39 |
8M0134502 |
CLAMP BRACKET Starboard
|
1 |
|
| 4 |
898101091 |
WIRE Ground
|
1 |
|
| 40 |
8M0134503 |
CLAMP BRACKET Port
|
1 |
|
| 41 |
823701004 |
DECAL Co-Pilot
|
1 |
|
| 42 |
823913Q |
ANODE
|
2 |
|
| 43 |
167051 |
BOLT (M6 x 20)
|
2 |
|
| 44 |
8M0135830 |
DISTANCE PIECE
|
1 |
|
| 45 |
16826 |
WASHER Stainless Steel
|
4 |
|
| 46 |
400212 |
NUT (M6) Stainless Steel
|
2 |
|
| 47 |
898101191 |
TILT TUBE ASSEMBLY
|
1 |
|
| 48 |
853722029 |
NUT Nylon
|
1 |
|
| 49 |
8537435 |
BUSHING
|
2 |
|
| 5 |
8M0135835 |
TILT STOPPER
|
1 |
superseded
|
| 50 |
85372214 |
CAP NUT
|
2 |
|
| 51 |
8M0135832 |
THRUST ROD ASSEMBLY
|
1 |
|
| 52 |
815093003 |
SPRING
|
1 |
|
| 53 |
815082002 |
HANDLE Carrying
|
1 |
|
| 54 |
8M0060117 |
CLAMP SCREW KIT
|
2 |
superseded
|
| 55 |
8M0137367 |
DECAL Secure Engine
|
1 |
superseded
|
| 56 |
8M0094877 |
SCREW (8 x 85mm
|
2 |
|
| 57 |
16192 |
WASHER
|
4 |
|
| 58 |
95374 |
NUT Nylon
|
2 |
|
| 6 |
898103104 |
PIN Spring
|
1 |
|
| 7 |
163364 |
BUSHING
|
1 |
|
| 8 |
853774 |
STOP
|
1 |
|
| 9 |
953832 |
SPRING
|
1 |
|
