| # | Part Number | Description | Qty | Status |
|---|
| - |
8M0238936 |
SEAL KIT Seals and O-rings for two injectors
|
1 |
|
| 1 |
8M0134458 |
FUEL RAIL ASSEMBLY
|
1 |
superseded
|
| 10 |
823042 |
BOLT
|
2 |
|
| 11 |
8M0134460 |
INSULATOR
|
1 |
|
| 12 |
8M0134463 |
VAPOR SEPERATOR ASSEMBLY
|
1 |
|
| 13 |
8M0135593 |
MOUNT Rubber
|
2 |
|
| 14 |
8M0137298 |
COLLAR
|
2 |
|
| 15 |
953921 |
WASHER Stainless Steel
|
2 |
|
| 16 |
4000330 |
SCREW (M6 x 25)
|
2 |
superseded
|
| 17 |
8M0132344 |
HOSE Fuel
|
1 |
|
| 18 |
898101237 |
CLAMP
|
2 |
|
| 19 |
8M0132216 |
HOSE Vent
|
1 |
|
| 2 |
8M0134459 |
FUEL INJECTOR ASSEMBLY
|
2 |
|
| 20 |
8M0135701 |
HOSE Vent
|
1 |
|
| 21 |
8M0135702 |
HOSE Vent
|
1 |
|
| 22 |
8M0138568 |
CLAMP
|
1 |
|
| 23 |
8M0138601 |
HOSE Water DRIVESHAFT HOUSING-FUEL COOLER
|
2 |
|
| 24 |
8M0138603 |
HOSE Cooling IDLE PORT COVER-NIPPLE [1R029247] & Below
|
1 |
|
| 25 |
8M0138605 |
HOSE Cooling IDLE PORT COVER-FUEL COOLER Design 1 [1R029247] & Below
|
1 |
|
| 26 |
8M0229095 |
HOSE Cooling IDLE PORT COVER Design 2 [1R029248] & Up
|
1 |
|
| 27 |
8M0137341 |
FITTING Nipple
|
2 |
|
| 28 |
8230427 |
BOLT ASSEMBLY (M6 x 12)
|
1 |
|
| 29 |
8M0057112 |
HOSE
|
1 |
|
| 3 |
8230427 |
BOLT ASSEMBLY (M6 x 12)
|
1 |
|
| 4 |
883542001 |
VALVE
|
1 |
superseded
|
| 5 |
805515001 |
CAP Valve
|
1 |
|
| 6 |
8M0135592 |
FITTING Nipple
|
1 |
|
| 7 |
804840007 |
O-RING
|
2 |
|
| 8 |
804830002 |
CLAMP
|
1 |
|
| 9 |
8M0138599 |
SEAL RING
|
2 |
|
