| # | Part Number | Description | Qty | Status |
|---|---|---|---|---|
| 1 | 8M0137317 | BRACKET Throttle Wire | 1 | |
| 10 | 8M0137318 | ROD Throttle | 1 | |
| 11 | 853745 | CAP | 2 | |
| 12 | 16081 | NUT Stainless Steel | 3 | |
| 13 | 8M0137312 | BALL JOINT | 1 | |
| 14 | 8M0134501 | SHAFT Shift Lever | 1 | superseded |
| 15 | 8M0135825 | ROD Shift, Short | 1 | superseded |
| 15 | 8M0135826 | ROD Shift, Long | 1 | superseded |
| 16 | 8M0135827 | JOINT Shift Rod | 1 | superseded |
| 17 | 8M0137340 | GROMMET | 1 | |
| 18 | 8M0135811 | HOLDER | 1 | |
| 19 | 8M0135812 | HOLDER | 1 | |
| 2 | 8M0140788 | CLAMP | 1 | |
| 20 | 167051 | BOLT (M6 x 20) | 4 | |
| 21 | 8230427 | BOLT ASSEMBLY (M6 x 12) | 1 | |
| 22 | 8M0135810 | SHIFT DETENT Supporter | 1 | |
| 23 | 8M0127937 | SWITCH Neutral | 1 | |
| 24 | 803841 | ACTUATOR | 1 | |
| 25 | 8M0135828 | BRACKET Neutral Switch | 1 | superseded |
| 26 | 8M0135809 | SHIFT DETENT Spring | 2 | |
| 27 | 8M0135813 | ARM Shift | 1 | |
| 28 | 8M0137300 | COLLAR | 1 | |
| 29 | 4000330 | SCREW (M6 x 25) | 1 | superseded |
| 3 | 8248324 | SCREW (M6 x 16) | 7 | |
| 30 | 8M0135854 | ROD Shift Lever | 1 | superseded |
| 31 | 953925 | WASHER | 2 | |
| 32 | 8M0021224 | CLIP Bow-Tie | 2 | |
| 4 | 8M0137313 | SPRING | 1 | |
| 5 | 953921 | WASHER Stainless Steel | 4 | |
| 6 | 8M0135707 | THROTTLE DRUM | 1 | superseded |
| 7 | 8M0137299 | COLLAR | 1 | |
| 8 | 4000333 | SCREW (M6 x 40) | 1 | |
| 9 | 8M0135708 | LINK ROD ASSEMBLY | 1 |
