| # | Part Number | Description | Qty | Status |
|---|---|---|---|---|
| 1 | 853775 | GRIP | 1 | superseded |
| 10 | 160572 | E RING | 2 | |
| 11 | 953832 | SPRING | 1 | |
| 12 | 853774 | STOP | 1 | |
| 13 | 8251131 | BRACKET | 1 | |
| 14 | 825112006 | STOPPER Tilt | 1 | superseded |
| 15 | 9521813 | PIN Spring | 1 | |
| 16 | 162101 | SET PLATE | 1 | superseded |
| 17 | 823042052 | BOLT | 2 | superseded |
| 18 | 8040244 | SPRING (Short) | 2 | |
| 18 | 8040245 | SPRING (Long)(X-Long) | 2 | |
| 19 | 804047 | ROD Reverse Lock | 1 | |
| 2 | 853776 | BUTTON | 1 | superseded |
| 20 | 804044 | LOCK Reverse (Starboard) | 1 | |
| 21 | 804045004 | ARM Reverse Lock | 1 | |
| 22 | 8040441 | LOCK Reverse (Port) | 1 | |
| 23 | 8150261 | COTTER PIN | 1 | |
| 24 | 804049001 | SHAFT | 1 | |
| 25 | 804024009 | SPRING | 1 | superseded |
| 26 | 804024010 | SPRING | 1 | superseded |
| 3 | 804049 | SHAFT/BOLT Reverse Lock Lever | 1 | superseded |
| 4 | 16826 | WASHER Stainless Steel | 3 | |
| 5 | 804048 | LEVER Tilt Stopper | 1 | disc. |
| 6 | 895118002 | WASHER | 1 | superseded |
| 7 | 8040246 | SPRING | 1 | |
| 8 | 804050 | LINK | 1 | |
| 9 | 804046003 | SHAFT Reverse Lock | 1 |
