| # | Part Number | Description | Qty | Status |
|---|
| - |
803996A1 |
HANDLE KIT [0N114790] & Below
|
1 |
superseded
|
| - |
803996T09 |
HANDLE KIT [0N114791] & Up
|
1 |
superseded
|
| 1 |
803996004 |
HANDLE Steering [0N114790] & Below
|
1 |
superseded
|
| 1 |
8M0047218 |
HANDLE Steering [0N114791] & Up
|
1 |
|
| 10 |
8116533 |
STUD
|
1 |
superseded
|
| 11 |
168261 |
WASHER
|
1 |
|
| 12 |
85372215 |
NUT
|
1 |
|
| 13 |
804018 |
WIRE Throttle
|
2 |
superseded
|
| 14 |
813026 |
FRICTION PIECE [0N114790] & Below
|
1 |
|
| 15 |
16087 |
SCREW Adjusting [0N114790] & Below
|
1 |
|
| 16 |
16826 |
WASHER Stainless Steel [0N114790] & Below
|
1 |
|
| 17 |
400212 |
NUT (M6) Stainless Steel [0N114790] & Below
|
1 |
|
| 18 |
803998 |
SHAFT Throttle
|
1 |
|
| 19 |
16336 |
BUSHING
|
1 |
|
| 2 |
16090 |
DECAL
|
1 |
superseded
|
| 20 |
16191 |
SPACER
|
1 |
|
| 21 |
8537152 |
SPACER
|
1 |
|
| 22 |
8150263 |
COTTER PIN
|
1 |
|
| 23 |
804055 |
BRACKET Support
|
1 |
|
| 24 |
8230427 |
BOLT ASSEMBLY (M6 x 12)
|
1 |
|
| 25 |
811654002 |
STUD [ON175257] & Below
|
2 |
superseded
|
| 25 |
8M0074787 |
STUD [ON175258] & Up
|
2 |
|
| 26 |
16192 |
WASHER [ON175257] & Below
|
2 |
|
| 26 |
8M0074789 |
WASHER [ON175258] & Up
|
2 |
|
| 27 |
95374 |
NUT Nylon [ON175257] & Below
|
2 |
|
| 27 |
8M0074788 |
NUT [ON175258] & Up
|
2 |
|
| 28 |
804019005 |
BRACKET Steering [ON175257] & Below
|
1 |
|
| 28 |
8M0074786 |
BRACKET Steering [ON175258] & Up
|
1 |
|
| 29 |
162636 |
BOLT
|
1 |
|
| 3 |
160861 |
GRIP
|
1 |
|
| 30 |
810755003 |
SCREW
|
1 |
superseded
|
| 31 |
895118002 |
WASHER
|
1 |
superseded
|
| 32 |
953951 |
CLAMP
|
1 |
|
| 33 |
82304234 |
BOLT
|
1 |
superseded
|
| 34 |
8537392 |
BRACKET Throttle Link
|
1 |
|
| 35 |
16223 |
BOLT (M6 x 14)
|
2 |
|
| 36 |
895106 |
WASHER Stainless Steel
|
2 |
superseded
|
| 37 |
898101311 |
FRICTION PIECE [0N114791] & Up
|
1 |
|
| 38 |
892776 |
NUT [0N114791] & Up
|
1 |
superseded
|
| 39 |
892777 |
SPRING Stainless Steel [0N114791] & Up
|
1 |
superseded
|
| 4 |
8150461 |
SCREW
|
1 |
|
| 40 |
879194250 |
BOLT [0N114791] & Up
|
1 |
superseded
|
| 5 |
8518582 |
BUSHING
|
1 |
|
| 6 |
8518581 |
BUSHING
|
1 |
|
| 7 |
804017 |
WAVE WASHER
|
1 |
|
| 8 |
804508 |
WASHER
|
1 |
|
| 9 |
803997A1 |
HOLDER ASSEMBLY Steering Handle
|
1 |
superseded
|
