| # | Part Number | Description | Qty | Status |
|---|
| 1 |
853742003 |
ARM Actuator
|
1 |
|
| 10 |
803157 |
SPRING Throttle Cam
|
1 |
|
| 11 |
895118002 |
WASHER
|
2 |
superseded
|
| 12 |
9528613 |
COLLAR
|
1 |
|
| 13 |
853744 |
BALL JOINT
|
2 |
superseded
|
| 14 |
400256 |
LOCKWASHER (M6)
|
2 |
|
| 15 |
8555612 |
L-LINK
|
1 |
superseded
|
| 16 |
8555616 |
L-LINK
|
1 |
|
| 17 |
853745 |
CAP
|
2 |
|
| 18 |
8537225 |
NUT
|
2 |
superseded
|
| 19 |
163332 |
SNAP Link Rod
|
2 |
|
| 2 |
16201 |
BOLT
|
1 |
|
| 20 |
853745003 |
SOCKET
|
1 |
superseded
|
| 21 |
953925 |
WASHER
|
1 |
|
| 22 |
8150262 |
COTTER PIN
|
1 |
|
| 23 |
803993 |
ARM Throttle Stop (Handle)
|
1 |
|
| 24 |
4000330 |
SCREW (M6 x 25) (Handle)
|
1 |
superseded
|
| 25 |
16826 |
WASHER Stainless Steel (Handle)
|
2 |
|
| 26 |
9528624 |
COLLAR (9.3 mm) (Handle)
|
1 |
superseded
|
| 27 |
803994 |
S-LINK (Handle)
|
2 |
|
| 28 |
8M0148747 |
ROD Snap (Handle)
|
4 |
|
| 3 |
161404 |
WASHER
|
2 |
|
| 4 |
9528612 |
COLLAR
|
1 |
|
| 5 |
16830 |
BOLT
|
1 |
|
| 6 |
400212 |
NUT (M6) Stainless Steel
|
1 |
|
| 7 |
8537501 |
CAM Throttle (40 Lightning XR/50)
|
1 |
|
| 7 |
8537502 |
CAM Throttle (40)
|
1 |
|
| 8 |
803156 |
LEVER Advancer
|
1 |
|
| 9 |
4000333 |
SCREW (M6 x 40)
|
1 |
|
