| # | Part Number | Description | Qty | Status |
|---|
| - |
8M0225922 |
STARTER ASSEMBLY Recoil
|
1 |
|
| - |
8M0231227 |
STARTER PULLEY
|
1 |
|
| 1 |
8M0129194 |
STARTER CASE
|
1 |
|
| 10 |
85374013 |
WIRE
|
1 |
|
| 11 |
8113683 |
SLEEVE
|
1 |
|
| 12 |
81502611 |
COTTER PIN
|
1 |
|
| 13 |
9539213 |
WASHER
|
1 |
|
| 14 |
804032 |
ARM Stopper
|
1 |
|
| 15 |
8040243 |
SPRING Stopper
|
1 |
|
| 16 |
8M0129205 |
GUIDE Rope
|
1 |
|
| 17 |
8M0129200 |
SCREW
|
3 |
|
| 18 |
804031 |
STOPPER Reel
|
1 |
|
| 19 |
804029 |
HANDLE Starter
|
1 |
|
| 2 |
8M0129206 |
SPRING Starter
|
1 |
|
| 20 |
8M0129204 |
ROPE Starter
|
1 |
|
| 21 |
853755002 |
CAP Starter Handle
|
1 |
|
| 22 |
8M0204707 |
SCREW M6 x 25 HX HD CAP SS
|
4 |
|
| 23 |
400256 |
LOCKWASHER (M6)
|
3 |
|
| 24 |
8M0231222 |
PULLEY Starter
|
1 |
disc.
|
| 25 |
8M0231224 |
BOLT
|
3 |
|
| 26 |
8M0231226 |
PLATE Starter Pulley
|
3 |
disc.
|
| 27 |
16826 |
WASHER Stainless Steel
|
2 |
|
| 28 |
8M0021168 |
COLLAR
|
1 |
|
| 29 |
804036 |
LOCK ARM Starter
|
1 |
|
| 3 |
8M0129197 |
REEL
|
1 |
|
| 4 |
8M0129207 |
SPRING Friction
|
1 |
|
| 5 |
8M0129210 |
PLATE Friction
|
1 |
|
| 6 |
8M0129199 |
SCREW
|
4 |
|
| 7 |
812635T03 |
RATCHET
|
1 |
|
| 8 |
8M0129198 |
SPRING Return
|
1 |
|
| 9 |
8M0129209 |
SPRING Return
|
1 |
|
