| # | Part Number | Description | Qty | Status |
|---|
| - |
804056A1 |
STARTER MOTOR KIT
|
1 |
superseded
|
| 1 |
8M0057107 |
BOTTOM COWL [0N255299] & Below
|
1 |
superseded
|
| 1 |
8M0143843 |
BOTTOM COWL ASSEMBLY Manual Tilt [0N255300] & Up
|
1 |
|
| 1 |
8M0143845 |
BOTTOM COWL ASSEMBLY Power Tilt [0N255300] & Up
|
1 |
|
| 10 |
8518503 |
GROMMET
|
1 |
|
| 11 |
162284 |
GROMMET
|
1 |
|
| 12 |
855549 |
PLUG
|
1 |
|
| 13 |
8M0085709 |
BRACKET Clutch Cable
|
1 |
superseded
|
| 14 |
823042075 |
SCREW
|
1 |
|
| 15 |
8M0085710 |
CLAMP Power Trim Switch
|
1 |
|
| 16 |
8248324 |
SCREW (M6 x 16)
|
1 |
|
| 17 |
8518506 |
GROMMET (Handle)
|
1 |
|
| 17 |
8518504 |
GROMMET (Remote Control)
|
1 |
|
| 18 |
8M0057108 |
SWITCH Power Trim
|
1 |
|
| 19 |
162234 |
BOLT (Power Trim)
|
2 |
|
| 2 |
8M0143846 |
PLUG Drain [0N255300] & Up
|
4 |
|
| 20 |
953871 |
GROMMET (Power Trim)
|
1 |
|
| 21 |
898101145 |
O-RING (Power Trim)
|
1 |
|
| 22 |
8M0057109 |
BRACKET (Power Trim)
|
2 |
|
| 23 |
16226 |
GROMMET (Manual Tilt)
|
1 |
|
| 24 |
823042044 |
BOLT
|
4 |
superseded
|
| 25 |
161404 |
WASHER
|
4 |
|
| 26 |
8M0085706 |
GROMMET (Power Trim)
|
1 |
superseded
|
| 27 |
8537154 |
SPACER
|
4 |
superseded
|
| 28 |
953922 |
WASHER
|
1 |
|
| 29 |
16221 |
WAVE WASHER
|
1 |
|
| 3 |
8537437 |
MOUNT Rubber
|
8 |
|
| 30 |
162222 |
COVER HOOK
|
1 |
superseded
|
| 31 |
8107552 |
BOLT
|
1 |
superseded
|
| 32 |
400256 |
LOCKWASHER (M6)
|
1 |
|
| 33 |
895118002 |
WASHER
|
1 |
superseded
|
| 34 |
162184 |
HOOK LEVER
|
1 |
|
| 35 |
16219 |
SEAL
|
1 |
|
| 36 |
16220 |
BUSHING
|
1 |
|
| 37 |
95306 |
CLAMP (Power Trim)
|
1 |
superseded
|
| 38 |
823042064 |
SCREW (Power Trim)
|
1 |
superseded
|
| 39 |
804051A1 |
LANYARD SWITCH (Handle)
|
1 |
|
| 4 |
16823 |
GROMMET
|
1 |
|
| 40 |
823054 |
LANYARD (Handle)
|
1 |
|
| 41 |
8518505 |
GROMMET
|
1 |
|
| 42 |
804052A1 |
MAIN SWITCH (Electric)
|
1 |
|
| 43 |
802989 |
KEY (Electric) (#301)
|
1 |
|
| 43 |
8029891 |
KEY (Electric) (#302)
|
1 |
|
| 43 |
8029892 |
KEY (Electric) (#303)
|
1 |
|
| 44 |
804054 |
NEUTRAL SWITCH (Electric)
|
1 |
superseded
|
| 45 |
9539211 |
WASHER (Electric)
|
1 |
|
| 46 |
8230427 |
BOLT ASSEMBLY (M6 x 12)
|
1 |
|
| 47 |
8M0057111 |
NIPPLE
|
1 |
|
| 5 |
162263 |
GROMMET (Manual)
|
1 |
|
| 6 |
16226 |
GROMMET (Non-Oil Injection)
|
1 |
|
| 7 |
804057 |
PILOT LAMP (Oil Injection)
|
1 |
|
| 8 |
16226 |
GROMMET
|
1 |
|
| 9 |
8518502 |
GROMMET
|
1 |
|
