| # | Part Number | Description | Qty | Status |
|---|
| - |
8M0142971 |
GASKET SET Powerhead
|
1 |
|
| 1 |
8M0237812 |
EXHAUST TUBE
|
1 |
|
| 10 |
8M0240716 |
RETAINING RING
|
1 |
|
| 11 |
8M0219258 |
VALVE GUIDE
|
1 |
|
| 12 |
8M0219259 |
SPRING Compression
|
1 |
|
| 13 |
8M0219257 |
POPPET VALVE
|
1 |
|
| 14 |
8M0210460 |
INLINE STRAINER ASSEMBLY
|
1 |
|
| 15 |
8M0103805 |
SCREW (M6 x 16mm) Stainless Steel
|
2 |
|
| 16 |
29439 |
O-RING
|
1 |
|
| 17 |
8M0204650 |
O-RING
|
1 |
|
| 18 |
8M0218107 |
FITTING Elbow
|
1 |
|
| 19 |
8M0237819 |
HOSE Water Inlet
|
1 |
|
| 2 |
8M0103805 |
SCREW (M6 x 16mm) Stainless Steel
|
3 |
|
| 20 |
8M0161579 |
CLAMP 93.7 MM
|
2 |
|
| 21 |
8M0172179 |
COUPLING Exhaust Assembly
|
1 |
|
| 22 |
8M0148727 |
CAP Vinyl
|
2 |
|
| 23 |
8M0219003 |
MANIFOLD Exhaust, Upper
|
1 |
|
| 24 |
8M0087451 |
PLUG (18MM)
|
1 |
|
| 25 |
8M0087453 |
PLUG (24 MM)
|
1 |
|
| 26 |
8M0142533 |
SCREW (M8 x 85)
|
1 |
|
| 27 |
88552645 |
SCREW (M8X45)
|
3 |
|
| 28 |
8M0142534 |
FITTING Sprayer
|
1 |
|
| 29 |
892446 |
O-RING (14 X 1.78 MM)
|
1 |
|
| 3 |
8M0177539 |
SCREW (M6 x 14) Torx Pan HD
|
1 |
|
| 30 |
8M0142536 |
FITTING Sprayer Cooling
|
1 |
|
| 31 |
863006 |
O-RING (10.82 x 1.78)
|
1 |
|
| 32 |
8M0103804 |
SCREW (M6 x 12 MM) Stainless Steel
|
1 |
|
| 33 |
8M0230977 |
SCREW (M6 x 25 MM)
|
1 |
|
| 4 |
8M0237818 |
EXHAUST COVER
|
1 |
|
| 5 |
8M0200201 |
SEAL Lower
|
1 |
|
| 6 |
8M0103806 |
SCREW (M6 x 20 MM) Stainless Steel
|
4 |
|
| 7 |
8M0150517 |
FITTING Water
|
1 |
|
| 8 |
8M0142481 |
O-RING (0.362 x 0.103)
|
1 |
|
| 9 |
8M0223839 |
POPPET VALVE ASSEMBLY
|
1 |
|
