| # | Part Number | Description | Qty | Status |
|---|---|---|---|---|
| - | 8M0184184 |
INLINE STRAINER KIT INLINE STRAINER KIT |
1 | |
| - | 8M0142971 |
КОМПЛЕКТ ПРОКЛАДОК Силовая головка GASKET SET Powerhead |
1 | |
| - | 8M0142278 |
ЛОНГ-БЛОК LONG BLOCK |
1 | |
| 1 | 8M0162139 |
THERMOSTAT ASSEMBLY THERMOSTAT ASSEMBLY |
1 | |
| 10 | 8M0187145 |
CLAMP CLAMP |
1 | |
| 11 | 8M0172178 |
FITTING ASSEMBLY FITTING ASSEMBLY |
1 | |
| 12 | 201951 |
УПЛОТНИТЕЛЬНОЕ КОЛЬЦО (0.487 x 0.103) O-RING (.487 x .103) |
1 | |
| 13 | 816311T |
ЛЕНТОЧНЫЙ ХОМУТ (8.00") TIE STRAP (8.00 Inches) |
18 | |
| 14 | 8M0142513 |
РУКАВ Water Sprayer Exhaust HOSE Water Sprayer Exhaust |
1 | |
| 15 | 8M0142610 |
РУКАВ Выпуск термостата HOSE Thermostat Outlet |
1 | |
| 16 | 8M0142511 |
РУКАВ Water Sprayer Exhaust HOSE Water Sprayer Exhaust |
1 | |
| 17 | 8M0142501 |
УПЛОТНИТЕЛЬНОЕ КОЛЬЦО Chap Plate GROMMET Chap Plate |
2 | |
| 18 | 8M0173463 |
FITTING Inlet FITTING Inlet |
1 | |
| 19 | 8M0204650 |
O-RING O-RING |
1 | |
| 2 | 8M0237809 |
SHIELD Thermostat SHIELD Thermostat |
1 | |
| 20 | 888988011 |
ЗАЖИМ (38,1 ММ) CLAMP (38.1 MM) |
2 | |
| 21 | 8M0172176 |
HOSE Water Inlet HOSE Water Inlet |
1 | |
| 22 | 8M0142506 |
ФИТИНГ Соединитель FITTING Connector |
1 | |
| 23 | 8M0142620 |
РУКАВ Water to Starboard Cylinder Head HOSE Water to Starboard Cylinder Head |
1 | |
| 24 | 8M0142507 |
Y-ОБРАЗНЫЙ ФИТИНГ Exhaust to Cylinder Head YFITTING Exhaust to Cylinder Head |
1 | |
| 25 | 26317 |
УПЛОТНИТЕЛЬНОЕ КОЛЬЦО O-RING (1.109 x .139) |
1 | |
| 26 | 8M0142621 |
РУКАВ Water to Port Cylinder Head HOSE Water to Port Cylinder Head |
1 | |
| 27 | 8M0142510 |
ФИТИНГ Water Inlet FITTING Water Inlet |
2 | |
| 28 | 8M0204650 |
O-RING O-RING |
1 | |
| 29 | 8M0142518 |
ШЛАНГ В СБОРЕ Cylinder Head Drain HOSE ASSEMBLY Cylinder Head Drain |
1 | |
| 3 | 8M0103806 |
ВИНТ (M6 x 20 мм), нержавеющая сталь SCREW (M6 x 20 MM) Stainless Steel |
9 | |
| 30 | 8M0203912 |
FITTING M10 x 1.5 FITTING M10 x 1.5 |
2 | |
| 31 | 8M0142523 |
УПЛОТНИТЕЛЬНОЕ КОЛЬЦО (В.Д. 8,1 ММ X 1,6 ММ) O-RING (8.1 MM ID X 1.6MM) |
1 | |
| 32 | 8M0161583 |
HOSE ASSEMBLY Water Outlet, Starboard HOSE ASSEMBLY Water Outlet, Starboard |
1 | |
| 33 | 884546 |
УПЛОТНИТЕЛЬНОЕ КОЛЬЦО GROMMET |
3 | |
| 34 | 8M0237808 |
HOSE ASSEMBLY Water Drain HOSE ASSEMBLY Water Drain |
1 | |
| 34 | 8M0237820 |
HOSE ASSEMBLY Water Drain ROS Models HOSE ASSEMBLY Water Drain ROS Models |
1 | |
| 35 | 899145 |
ЗАЖИМ Ленточный хомут CLIP Tie Strap |
1 | |
| 36 | 888523001 |
ЗАЖИМ CLIP |
1 | |
| 37 | 8M0142524 |
РУКАВ Strainer to Fuel Supply Module Inlet HOSE Strainer to Fuel Supply Module Inlet |
1 | |
| 38 | 8M0237798 |
HOSE Strainer to Mount Cooler Strainer to Mount Cooler HOSE Strainer to Mount Cooler Strainer to Mount Cooler |
1 | |
| 38 | 8M0239131 |
HOSE Strainer to Mount Cooler Strainer to Mount Cooler, ROS Models HOSE Strainer to Mount Cooler Strainer to Mount Cooler, ROS Models |
1 | |
| 39 | 8M0142496 |
ШЛАНГ В СБОРЕ Выпуск воды, левый борт HOSE ASSEMBLY Water Outlet, Port |
1 | |
| 4 | 8M0142494 |
ФИТИНГ Water Outlet FITTING Water Outlet |
1 | |
| 40 | 8M0142497 |
ФИТИНГ Слив промывки FITTING Flush Drain |
1 | |
| 41 | 8M0153722 |
HOSE ASSEMBLY Flush HOSE ASSEMBLY Flush |
1 | |
| 42 | 8M0142530 |
ШЛАНГ В СБОРЕ HOSE ASSEMBLY |
1 | |
| 43 | 8M0156634 |
HOSE HOSE |
1 | |
| 44 | 8M0157397 |
ЗАЖИМ Oetiker, 17,5 CLAMP Oetiker, 17.5 |
1 | |
| 45 | 8M0142531 |
ЗАЖИМ CLIP |
1 | |
| 46 | 8M0142509 |
ФИТИНГ Соединитель FITTING Connector |
1 | |
| 47 | 8M0183167 |
HOSE Strainer to Manifold HOSE Strainer to Manifold |
1 | |
| 48 | 888988019 |
ЗАЖИМ (22.6 мм) CLAMP (22.6 mm) |
2 | |
| 5 | 35480 |
УПЛОТНИТЕЛЬНОЕ КОЛЬЦО (1.237 x 0.103) O-RING (1.237 x .103) |
1 | |
| 6 | 8M0028753 |
ЗАЖИМ Oetiker (диаметр 31,6) CLAMP Oetiker (31.6 Diameter) |
7 | |
| 7 | 8M0142503 |
РУКАВ Охлаждение Port Cylinder to Exhaust HOSE Cooling Port Cylinder to Exhaust |
1 | |
| 8 | 8M0142516 |
ФИТИНГ Зазубренный FITTING Barbed |
1 | |
| 9 | 8M0142517 |
УПЛОТНИТЕЛЬНОЕ КОЛЬЦО (В.Д. 23,6 ММ X 2,9 ММ) O-RING (23.6 MM ID X 2.9 MM) |
1 |
