| # | Part Number | Description | Qty | Status |
|---|
| - |
8M0171478 |
CABLE Battery Isolator
|
1 |
|
| - |
8M0227901 |
HARNESS Trim Relay
|
1 |
|
| 1 |
8M0227658 |
PCM 400R DTS AMS
|
1 |
|
| 10 |
8M0103805 |
SCREW (M6 x 16mm) Stainless Steel
|
2 |
|
| 11 |
8M0207797 |
FUSE Mini Gray 2 Ampere
|
AR |
|
| 11 |
832969T05 |
FUSE Mini - Tan - 5 Ampere
|
AR |
|
| 11 |
83296910 |
FUSE Mini - Red - 10 Ampere
|
AR |
|
| 11 |
832969T15 |
FUSE Mini - Blue - 15 Ampere
|
AR |
|
| 11 |
832969T20 |
FUSE Mini - Yellow - 20 Ampere
|
AR |
|
| 12 |
8M0047886 |
HOLDER Spare Fuse
|
3 |
|
| 13 |
NSS |
NOT SOLD SEPARATE Mount-Fuse Block
|
1 |
|
| 14 |
8M0147903 |
SEAL Fuse Box
|
1 |
|
| 15 |
8M0199922 |
COVER Fuse Block
|
1 |
|
| 16 |
816311T |
TIE STRAP (8.00 Inches)
|
6 |
|
| 17 |
8M0199923 |
BRACKET Ten Pin
|
1 |
|
| 18 |
8M0199924 |
SCREW M8 x 25 TRUSS HEAD
|
2 |
|
| 19 |
822003 |
BUSHING
|
4 |
|
| 2 |
8M0219598 |
SCREW M8 x 25 HEX FLG
|
4 |
|
| 20 |
8349851 |
GROMMET
|
4 |
|
| 21 |
8M0179913 |
NUT (M8)
|
11 |
|
| 22 |
8M0199925 |
PLATE Rigging
|
1 |
superseded
|
| 23 |
8M0129535 |
FUSE BLOCK 80 Amp - Lime
|
2 |
|
| 24 |
8M0207455 |
FUSE BLOCK 40 AMP
|
2 |
|
| 25 |
8M0174088 |
FUSE BLOCK 175 AMP
|
2 |
|
| 26 |
8M0096302 |
GROMMET
|
3 |
|
| 27 |
8M0199926 |
SPACER 15 Inch
|
5 |
superseded
|
| 28 |
8M0142686 |
SCREW (M6 x 25)
|
4 |
|
| 29 |
65567 |
WASHER (.265 x .750 x .048) Stainless Steel
|
4 |
|
| 3 |
4002318 |
WASHER 8.90 x 24.0x 2.4 PL SS
|
6 |
|
| 30 |
8M0179328 |
BAR Buss
|
1 |
|
| 31 |
8M0179329 |
LINK FUSE
|
1 |
|
| 32 |
8M0199927 |
COVER Rigging Plate
|
1 |
|
| 33 |
8M0179338 |
BOOT Alternator
|
1 |
|
| 34 |
8M0199930 |
HARNESS Hot Stud to Alternator
|
1 |
|
| 35 |
8M0199929 |
HARNESS Ground
|
1 |
|
| 36 |
8M0149414 |
CABLE KIT Battery
|
1 |
|
| 37 |
8M0149415 |
CABLE Engine to Hot Stud (12ft) Negative
|
1 |
|
| 38 |
8M0149416 |
CABLE Engine to Hot Stud (12ft) Positive
|
1 |
|
| 39 |
8M0199931 |
HARNESS Hot Stud to Starter
|
1 |
|
| 4 |
833155 |
GROMMET
|
6 |
|
| 40 |
8M0214963 |
WASHER Located between plate and terminal
|
2 |
|
| 5 |
8M0199920 |
BUSHING
|
6 |
|
| 6 |
878609 |
SCREW (#10-16 x .600)
|
2 |
|
| 7 |
42118 |
WASHER
|
2 |
|
| 8 |
834985 |
GROMMET
|
2 |
superseded
|
| 9 |
8M0199921 |
BRACKET
|
1 |
|
