| # | Part Number | Description | Qty | Status |
|---|
| - |
8M0149557 |
LONG BLOCK
|
1 |
|
| - |
8M0147117 |
POWERHEAD GASKET SET
|
1 |
|
| 1 |
8M0150490 |
CYLINDER HEAD ASSEMBLY Starboard
|
1 |
superseded
|
| 1 |
8M0150491 |
CYLINDER HEAD ASSEMBLY Port
|
1 |
superseded
|
| 10 |
8M0087453 |
PLUG (24 MM)
|
6 |
|
| 11 |
8M0087454 |
PLUG (30 MM)
|
2 |
|
| 12 |
8M0142364 |
VALVE Key
|
32 |
|
| 13 |
8M0142363 |
RETAINER
|
32 |
|
| 14 |
8M0142360 |
SPRING
|
32 |
|
| 15 |
8M0142359 |
SEAL Valve
|
32 |
|
| 16 |
8M0142361 |
VALVE Intake
|
16 |
|
| 17 |
8M0142362 |
VALVE Exhaust
|
16 |
|
| 18 |
892454030 |
SCREW (M6 x 30)
|
4 |
|
| 19 |
8M0142367 |
TENSIONER
|
2 |
|
| 2 |
8M0142354 |
VALVE Seat, Intake
|
16 |
|
| 20 |
8M0142366 |
CHAIN Cam to Cam
|
2 |
|
| 21 |
8M0142411 |
CAMSHAFT Exhaust, Starboard
|
1 |
|
| 21 |
8M0142416 |
CAMSHAFT Exhaust, Port
|
1 |
|
| 22 |
8M0149556 |
CAMSHAFT Intake, Starboard
|
1 |
|
| 22 |
8M0149555 |
CAMSHAFT Intake, Port
|
1 |
|
| 23 |
8M0142365 |
TAPPET (3.000)
|
32/AR |
|
| 23 |
8M0142431 |
TAPPET (3.015)
|
32/AR |
|
| 23 |
8M0142439 |
TAPPET (3.030)
|
32/AR |
|
| 23 |
8M0142440 |
TAPPET (3.045)
|
32/AR |
|
| 23 |
8M0142441 |
TAPPET (3.060)
|
32/AR |
|
| 23 |
8M0142438 |
TAPPET (3.075)
|
32/AR |
|
| 23 |
8M0142495 |
TAPPET (3.090)
|
32/AR |
|
| 23 |
8M0142492 |
TAPPET (3.105)
|
32/AR |
|
| 23 |
8M0142443 |
TAPPET (3.120)
|
32/AR |
|
| 23 |
8M0142447 |
TAPPET (3.135)
|
32/AR |
|
| 23 |
8M0142464 |
TAPPET (3.150)
|
32/AR |
|
| 23 |
8M0142465 |
TAPPET (3.165)
|
32/AR |
|
| 23 |
8M0142466 |
TAPPET (3.180)
|
32/AR |
|
| 23 |
8M0142487 |
TAPPET (3.195)
|
32/AR |
|
| 23 |
8M0142488 |
TAPPET (3.210)
|
32/AR |
|
| 23 |
8M0142489 |
TAPPET (3.225)
|
32/AR |
|
| 23 |
8M0142490 |
TAPPET (3.240)
|
32/AR |
|
| 23 |
8M0142491 |
TAPPET (3.255)
|
32/AR |
|
| 23 |
8M0142519 |
TAPPET (3.270)
|
32/AR |
|
| 23 |
8M0142520 |
TAPPET (3.285)
|
32/AR |
|
| 23 |
8M0142521 |
TAPPET (3.300)
|
32/AR |
|
| 23 |
8M0142525 |
TAPPET (3.315)
|
32/AR |
|
| 23 |
8M0142527 |
TAPPET (3.330)
|
32/AR |
|
| 23 |
8M0142532 |
TAPPET (3.345)
|
32/AR |
|
| 23 |
8M0142613 |
TAPPET (3.360)
|
32/AR |
|
| 23 |
8M0142252 |
TAPPET (3.375)
|
32/AR |
|
| 23 |
8M0142255 |
TAPPET (3.390)
|
32/AR |
|
| 23 |
8M0142256 |
TAPPET (3.405)
|
32/AR |
|
| 23 |
8M0142257 |
TAPPET (3.420)
|
32/AR |
|
| 23 |
8M0142258 |
TAPPET (3.435)
|
32/AR |
|
| 23 |
8M0142261 |
TAPPET (3.450)
|
32/AR |
|
| 23 |
8M0142263 |
TAPPET (3.465)
|
32/AR |
|
| 23 |
8M0142277 |
TAPPET (3.480)
|
32/AR |
|
| 23 |
8M0142291 |
TAPPET (3.495)
|
32/AR |
|
| 23 |
8M0142292 |
TAPPET (3.510)
|
32/AR |
|
| 23 |
8M0142666 |
TAPPET (3.525)
|
32/AR |
|
| 23 |
8M0142667 |
TAPPET (3.540)
|
32/AR |
|
| 23 |
8M0142668 |
TAPPET (3.555)
|
32/AR |
|
| 23 |
8M0142669 |
TAPPET (3.570)
|
32/AR |
|
| 23 |
8M0142670 |
TAPPET (3.585)
|
32/AR |
|
| 23 |
8M0142698 |
TAPPET (3.600)
|
32/AR |
|
| 23 |
8M0142699 |
TAPPET (3.615)
|
32/AR |
|
| 23 |
8M0142700 |
TAPPET (3.630)
|
32/AR |
|
| 23 |
8M0142701 |
TAPPET (3.645)
|
32/AR |
|
| 23 |
8M0142702 |
TAPPET (3.660)
|
32/AR |
|
| 23 |
8M0142703 |
TAPPET (3.675)
|
32/AR |
|
| 23 |
8M0142704 |
TAPPET (3.690)
|
32/AR |
|
| 24 |
8M0142369 |
SCREW (M10 x 107) TORX FLG HD
|
20 |
|
| 25 |
8M0168894 |
SCREW M6 x 35
|
4 |
superseded
|
| 26 |
8M0142273 |
GASKET Cylinder Head Starboard
|
1 |
|
| 26 |
8M0142272 |
GASKET Cylinder Head Port
|
1 |
|
| 27 |
8M0142368 |
O-RING (230 2.484 x .139)
|
1 |
|
| 28 |
8M0142537 |
GASKET Exhaust Manifold
|
1 |
|
| 3 |
8M0142355 |
VALVE Seat, Exhaust
|
16 |
|
| 4 |
8M0142358 |
VALVE Guide
|
32 |
|
| 5 |
NSS |
NOT SOLD SEPARATE Cap-Camshaft
|
18 |
|
| 6 |
8M0163131 |
SCREW M6
|
36 |
|
| 7 |
8M0142357 |
PLUG (21 MM) Special
|
6 |
|
| 8 |
8M0087447 |
PLUG (10MM)
|
12 |
|
| 9 |
8M0087451 |
PLUG (18MM)
|
2 |
|
