| # | Part Number | Description | Qty | Status |
|---|
| 1 |
8M0142593 |
LOWER COWL ASSEMBLY Black, Port and Starboard
|
1 |
|
| 1 |
8M0142607 |
LOWER COWL ASSEMBLY Cold Fusion, Port and Starboard
|
1 |
|
| 10 |
8M0142929 |
RETAINER Front, Starboard
|
1 |
|
| 11 |
8M0142972 |
PLATE
|
1 |
|
| 12 |
8M0047718 |
SCREW (M5 X 8MM)
|
2 |
|
| 13 |
888958001 |
PLUG Flush Port
|
1 |
superseded
|
| 14 |
8M0047301 |
SEAL Flush Plug Pocket
|
1 |
superseded
|
| 15 |
889823001 |
TETHER Flush Plug
|
1 |
superseded
|
| 16 |
885361A01 |
FITTING ASSEMBLY Flush
|
1 |
|
| 17 |
8M0032848 |
RETAINER Switch
|
1 |
|
| 18 |
8M0037225 |
TRIM SWITCH Round Bezel
|
1 |
superseded
|
| 19 |
8M0142945 |
GUIDE Front, Port
|
1 |
|
| 2 |
8M0142918 |
SCREW (M5 x 12)
|
8 |
|
| 20 |
8M0142918 |
SCREW (M5 x 12)
|
4 |
|
| 21 |
8M0142940 |
BUMPER
|
2 |
|
| 22 |
8M0022324 |
SCREW (M6 x 25 MM)
|
8 |
superseded
|
| 23 |
8M0073002 |
SCREW (M6 X 20), Hex Flg
|
2 |
|
| 24 |
8M0142709 |
LOWER FRONT COWL ASSEMBLY Black
|
1 |
|
| 24 |
8M0142717 |
LOWER FRONT COWL ASSEMBLY Cold Fusion, White
|
1 |
|
| 25 |
8M0142932 |
STRIKER ASSEMBLY Front
|
1 |
|
| 26 |
8M0142941 |
GROMMET
|
1 |
|
| 27 |
8M0142936 |
COVER CRADLE Front
|
1 |
|
| 28 |
8M0187300 |
SCREW M6 x 1
|
16 |
superseded
|
| 29 |
8M0177044 |
COVER CRADLE SET Silver
|
1 |
|
| 3 |
8M0142923 |
RETAINER Rear, Port
|
1 |
|
| 30 |
8M0142939 |
SOUND BLANKET Port
|
1 |
|
| 31 |
8M0142957 |
SOUND BLANKET Starboard
|
1 |
|
| 32 |
8M0075735 |
SCREW (M6 X 30) Hex Flg
|
3 |
|
| 33 |
8M0142935 |
ADAPTER
|
1 |
|
| 34 |
8M0142934 |
GROMMET Ingress
|
1 |
|
| 34 |
8M0146955 |
GROMMET Large Hole, DTS
|
1 |
|
| 35 |
8M0142944 |
GUIDE Front, Starboard
|
1 |
|
| 36 |
8M0071078 |
SCREW (M6 X 85) Hex Flg
|
1 |
superseded
|
| 37 |
8M0142933 |
SCREW (M6 x 40)
|
1 |
superseded
|
| 38 |
8M0142942 |
GUIDE Rear, Starboard
|
1 |
|
| 39 |
8M0142223 |
LOWER REAR COWL ASSEMBLY Black
|
1 |
|
| 39 |
8M0142225 |
LOWER REAR COWL ASSEMBLY Cold Fusion, White
|
1 |
|
| 4 |
8M0142922 |
RETAINER Front, Port
|
1 |
|
| 40 |
8M0142943 |
GUIDE Rear, Port
|
1 |
|
| 41 |
8M0142577 |
DECAL Read Manual, Clear
|
1 |
|
| 41 |
8M0142371 |
DECAL Read Manual, Black
|
1 |
|
| 42 |
4002315 |
WASHER (6.60 X 12.5 X 1.5 mm -SS)
|
5 |
|
| 43 |
8M0149605 |
SLEEVE Edge Protector
|
1 |
|
| 5 |
8M0159585 |
SEAL KIT Lower Front
|
1 |
|
| 6 |
8M0142919 |
STRIKER ASSEMBLY Port
|
1 |
|
| 7 |
8M0142921 |
SCREW (M6 X 16)
|
9 |
|
| 8 |
8M0142925 |
STRIKER ASSEMBLY Starboard
|
1 |
|
| 9 |
8M0142930 |
RETAINER Rear, Starboard
|
1 |
|
| NS |
8M0142960 |
SOUND BLANKET Front
|
1 |
|
