| # | Part Number | Description | Qty | Status |
|---|
| - |
8M0205845 |
HARDWARE UPGRADE KIT Driveshaft Housing
|
1 |
|
| 1 |
8M0210458 |
DRIVESHAFT HOUSING Graphite Grey
|
1 |
|
| 1 |
8M0214502 |
DRIVESHAFT HOUSING Cold Fusion White
|
1 |
|
| 10 |
8M0200079 |
CLAMP Design 1
|
1 |
|
| 10 |
8M0222234 |
CLAMP Design 2
|
1 |
|
| 11 |
8M0103807 |
SCREW (M6 x 25 mm) Stainless Steel
|
1 |
|
| 12 |
8M0142714 |
FITTING
|
1 |
|
| 13 |
816311T |
TIE STRAP (8.00 Inches)
|
2 |
|
| 14 |
85944975 |
TUBING (72.00 Inches Bulk)
|
1 |
|
| 15 |
821327 |
PIN Dowel
|
2 |
|
| 16 |
8M0142784 |
BRACKET Shift Harness
|
1 |
|
| 17 |
8M0142785 |
BRACKET Shift Harness
|
1 |
|
| 18 |
8M0142778 |
WASHER Mount Snubber
|
4 |
|
| 18 |
8M0200009 |
WASHER Mount Snubber Tie Bar Model Only
|
4 |
|
| 19 |
8M0112869 |
OIL PLUG ASSEMBLY
|
1 |
|
| 2 |
8M0205786 |
BRACKET Mount Support
|
2 |
superseded
|
| 20 |
85045 |
O-RING (.551 x .070)
|
1 |
|
| 21 |
863006 |
O-RING (10.82 x 1.78)
|
1 |
|
| 22 |
8M0036228 |
O-RING (8.1 X 1.6)
|
1 |
|
| 23 |
8M0164308 |
Bracket Assembly Graphite Grey
|
1 |
superseded
|
| 23 |
8M0164309 |
Bracket Assembly Cold Fusion White
|
1 |
superseded
|
| 24 |
8M0008031 |
STUD (M12 x 1.75 x 52) Long Models
|
5 |
|
| 24 |
8M0142781 |
STUD (M12 x 179) XLong Models
|
5 |
|
| 24 |
8M0142788 |
STUD (M12 x 306) XXLong Models
|
5 |
|
| 25 |
856982 |
WASHER (.500 x .810 x .090) Stainless Steel
|
5 |
|
| 26 |
896895 |
NUT (M12)
|
5 |
|
| 27 |
8M0147675 |
CLIP
|
1 |
|
| 28 |
8M0147674 |
BOOT Shift Actuator Wires
|
1 |
|
| 29 |
69355 |
TIE STRAP (5.50 Inches)
|
1 |
superseded
|
| 3 |
8M0200075 |
SCREW
|
6 |
superseded
|
| 30 |
8M0142253 |
SHIFT ACTUATOR
|
1 |
superseded
|
| 30 |
8M0175849 |
SHIFT ACTUATOR Tie Bar Model Only
|
1 |
superseded
|
| 31 |
8M0142978 |
SEAL ACTUATOR
|
1 |
|
| 32 |
8M0147857 |
SHAFT Coupling
|
1 |
|
| 33 |
8M0142829 |
SCREW (M6 x 20)
|
4 |
|
| 4 |
8M0200071 |
CABLE ASSEMBLY
|
1 |
|
| 5 |
8M0103804 |
SCREW (M6 x 12 MM) Stainless Steel
|
1 |
|
| 6 |
8M0200169 |
GUIDE Water Tube
|
1 |
|
| 7 |
8M0200170 |
EXTENSION Water Tube XLong Models
|
1 |
|
| 7 |
8M0200173 |
EXTENSION Water Tube XXLong Models
|
1 |
|
| 8 |
8M0200171 |
COUPLING
|
1 |
|
| 9 |
8M0103805 |
SCREW (M6 x 16mm) Stainless Steel Design 1
|
2 |
|
| 9 |
8M0144417 |
SCREW (M6 x 16) Design 2
|
2 |
|
