| # | Part Number | Description | Qty | Status |
|---|
| - |
8M0162824 |
LONG BLOCK
|
1 |
|
| 1 |
8M0142417 |
CRANKSHAFT
|
1 |
|
| 10 |
8M0142381 |
PISTON RING ASSEMBLY
|
8 |
|
| 11 |
NSS |
NOT SOLD SEPARATE CIRCLIP
|
16 |
|
| 12 |
8M0159647 |
CONNECTING ROD Design I (Must Use Design I Bolt)
|
8 |
|
| 12 |
8M0200039 |
CONNECTING ROD ASSEMBLY Design II (Must Use Design II Bolt)
|
8 |
superseded
|
| 13 |
8M0159648 |
BOLT, CONNECTING ROD Design I (Must Use Design I Bolt)
|
16 |
|
| 13 |
8M0206041 |
BOLT Connecting Rod Design II (Must Use Design II Bolt)
|
16 |
|
| 2 |
8M0147976 |
BEARING MAIN Green
|
AR |
|
| 2 |
8M0147977 |
BEARING MAIN Blue
|
AR |
|
| 2 |
8M0147978 |
BEARING MAIN White
|
AR |
|
| 2 |
8M0147979 |
BEARING MAIN Orange
|
AR |
|
| 3 |
8M0142386 |
RING RETAINING
|
1 |
|
| 4 |
8M0142379 |
SEAL Main Bearing
|
1 |
superseded
|
| 5 |
8M0142385 |
SPACER
|
1 |
|
| 6 |
8M0034912 |
O-RING 3.78 X 21.32
|
1 |
|
| 7 |
8M0142424 |
WASHER THRUST
|
2 |
|
| 8 |
8M0148077 |
BEARING Connecting Rod, Green
|
AR |
superseded
|
| 8 |
8M0148078 |
BEARING Connecting Rod, Blue
|
AR |
superseded
|
| 8 |
8M0148079 |
BEARING Connecting Rod, White
|
AR |
superseded
|
| 9 |
8M0159646 |
PISTON ASSEMBLY Design I [1E083006] THRU [1E085931]
|
8 |
superseded
|
| 9 |
8M0169558 |
PISTON ASSEMBLY Design II [1E085932] & Up
|
8 |
|
