| # | Part Number | Description | Qty | Status |
|---|
| - |
8M0142293 |
GEAR HOUSING ASSEMBLY Black (Standard Long) (1.85)
|
1 |
superseded
|
| - |
8M0142295 |
GEAR HOUSING ASSEMBLY Black (Standard X-Long) (1.85)
|
1 |
superseded
|
| - |
8M0142300 |
GEAR HOUSING ASSEMBLY Black (Standard XX-Long) (1.85)
|
1 |
superseded
|
| - |
8M0142294 |
GEAR HOUSING ASSEMBLY Silver (Standard Long) (1.85)
|
1 |
superseded
|
| - |
8M0142296 |
GEAR HOUSING ASSEMBLY Silver (Standard X-Long) (1.85)
|
1 |
superseded
|
| - |
8M0142299 |
GEAR HOUSING ASSEMBLY Silver (Standard XX-Long) (1.85)
|
1 |
superseded
|
| - |
8M0142979 |
SEAL KIT
|
1 |
|
| 1 |
8M0142886 |
GEAR HOUSING ASSEMBLY Basic, Black (4.8)
|
1 |
|
| 1 |
8M0145768 |
GEAR HOUSING ASSEMBLY Basic, Silver (4.8)
|
1 |
superseded
|
| 10 |
8M0142836 |
BEARING Roller Taper (Cup/Cone)
|
1 |
|
| 11 |
8M0046215 |
CRANK, Shifter 1/4 Pivot Pin
|
1 |
superseded
|
| 12 |
8M0142857 |
SPOOL ASSEMBLY
|
1 |
superseded
|
| 13 |
8M0045493 |
PIN Cross
|
1 |
|
| 14 |
8M0142849 |
CLUTCH Sliding
|
1 |
|
| 15 |
8M0050575 |
SPRING Cross
|
1 |
|
| 16 |
8M0142883 |
SHAFT Prop
|
1 |
|
| 17 |
8M0064306 |
SPACER Thrust
|
1 |
|
| 18 |
8M0076745 |
SHIM SET
|
1 |
|
| 19 |
8M0142890 |
BEARING CARRIER
|
1 |
|
| 2 |
8M0142853 |
PLUG Torpedo
|
1 |
superseded
|
| 20 |
8M0142891 |
GEAR Reverse, 24T
|
1 |
|
| 21 |
8M0142873 |
BEARING Ball
|
1 |
|
| 22 |
888483 |
SEAL Oil
|
2 |
superseded
|
| 23 |
880699 |
THRUST RING
|
1 |
|
| 24 |
8M0142840 |
O-RING (3.85 x 0.210)
|
1 |
|
| 25 |
8M0148319 |
BEARING Roller Taper Cup/Cone
|
1 |
|
| 26 |
8M0063270 |
SHIM SET
|
1 |
|
| 27 |
8M0109164 |
PIN 3/8 Dia x .625 LG
|
1 |
|
| 28 |
830749 |
SEAL
|
2 |
superseded
|
| 29 |
8M0071653 |
SCREW Special, .375-16 UNC
|
2 |
|
| 3 |
8M0142854 |
O-RING (2.175 x .103)
|
1 |
|
| 30 |
8M0142855 |
TAB WASHER
|
1 |
|
| 31 |
8M2000347 |
RETAINER
|
1 |
superseded
|
| 4 |
880719 |
RING Retaining
|
1 |
|
| 5 |
8M0063270 |
SHIM SET
|
1 |
|
| 6 |
NSS |
NOT SOLD SEPARATE Forward Gear
|
1 |
|
| 7 |
8M0053823 |
WASHER Thrust, (1.50 ID x 2.046 OD)
|
1 |
|
| 8 |
8M0051043 |
RING Retaining
|
1 |
|
| 9 |
8M0142835 |
BEARING Roller Taper (Cup/Cone)
|
1 |
|
