| # | Part Number | Description | Qty | Status |
|---|
| - |
8M0088072 |
GEARCASE Complete Long
|
1 |
|
| - |
8M0144823 |
GEARCASE Complete, Long Silver
|
1 |
superseded
|
| - |
8M0088074 |
GEARCASE Complete X-Long
|
1 |
|
| - |
8M0144824 |
GEARCASE Complete, X-Long Silver
|
1 |
superseded
|
| - |
8M0090442 |
SKEG
|
1 |
|
| - |
8M0088080 |
GEARCASE SEAL KIT
|
1 |
|
| 1 |
8M0091538 |
GEARCASE Basic
|
1 |
|
| 1 |
8M0145316 |
GEAR HOUSING Basic Silver
|
1 |
|
| 10 |
8M0077490 |
CAM Shift
|
1 |
|
| 11 |
8M0065168 |
CLUTCH Sliding
|
1 |
|
| 12 |
8M0065417 |
PIN Cross
|
1 |
|
| 13 |
30893 |
SPRING
|
1 |
|
| 14 |
8M0088077 |
SHAFT Propeller (RH)
|
1 |
|
| 15 |
8M0090832 |
GEAR Reverse 29T
|
1 |
|
| 16 |
8M0065430 |
BEARING Ball
|
1 |
superseded
|
| 17 |
8M0053099 |
THRUST RING
|
1 |
|
| 18 |
8M0065566 |
O-RING
|
1 |
|
| 19 |
8M0065046 |
SPOOL Bearing Carrier
|
1 |
superseded
|
| 2 |
8M0094470 |
GEAR SET Forward/Pinion
|
1 |
|
| 20 |
30956T |
BEARING Needle
|
1 |
|
| 21 |
8M0077071 |
SCREW/SEAL KIT
|
1 |
|
| 22 |
830749 |
SEAL
|
1 |
superseded
|
| 23 |
14077 |
SEAL Oil
|
1 |
|
| 24 |
76868 |
SEAL
|
1 |
superseded
|
| 24 |
12224 |
SEAL Fish Line Cutting
|
1 |
|
| 25 |
8M0032502 |
WASHER Keyed
|
1 |
|
| 26 |
8M0069653 |
BEARING CARRIER Retainer
|
1 |
superseded
|
| 27 |
8M0070256 |
SLEEVE Prop Bore Not used with 8M0185683 bearing retainer
|
1 |
superseded
|
| 3 |
8M0057742 |
BEARING Needle
|
1 |
|
| 4 |
8M0029306 |
RING Retaining
|
1 |
|
| 5 |
8M0094472 |
TAPERED ROLLER BEARING, SET
|
1 |
|
| 6 |
NSS |
NOT SOLD SEPARATE
|
1 |
|
| 7 |
8M0063266 |
SHIM SET
|
1 |
|
| 8 |
8M0057749 |
ROD Clutch Actuator
|
1 |
|
| 9 |
8M0072550 |
FOLLOWER Cam, (RH)
|
1 |
|
