| # | Part Number | Description | Qty | Status |
|---|---|---|---|---|
| 1 | 8M0074364 |
ПРОБКА COVER Hose Clamp |
AR | |
| 10 | 863129 |
ШАРИК BALL |
2 | |
| 11 | 864701 |
УПЛОТНИТЕЛЬНОЕ КОЛЬЦО (1.112 x 0.103) O-RING (1.112 x .103) |
2 | |
| 12 | 862994T |
ФИТИНГ FITTING |
2 | |
| 13 | 815504212 |
ЗАЖИМ Червячная передача CLAMP Worm Gear |
7 | |
| 14 | 8M0095813 |
РУКАВ T Fitting to Elbow HOSE T Fitting to Elbow |
1 | |
| 15 | 8M0095765 |
РУКАВ Upper Drain Fitting to T Fitting HOSE Upper Drain Fitting to T Fitting |
1 | |
| 16 | 863478 |
ФИТИНГ Тройник FITTING Tee |
1 | |
| 17 | 8M0095761 |
РУКАВ Low Drain to T Fitting HOSE Low Drain to T Fitting |
1 | |
| 18 | 8M0095814 |
РУКАВ T Drain to Lower Elbow HOSE T Drain to Lower Elbow |
1 | |
| 19 | 8M0082286 |
РУКАВ Steering Cooler to Y Fitting HOSE Steering Cooler to Y Fitting |
1 | superseded |
| 2 | 815504216 |
ЗАЖИМ Червячная передача (диаметр 1.56) CLAMP Worm Gear (1.56 Diameter) |
12 | |
| 20 | 8M0097146 |
РУКАВ Y Fitting to T Fitting HOSE Y Fitting to T Fitting |
1 | |
| 21 | 8M2003728 |
Y-ОБРАЗНЫЙ ФИТИНГ Y-FITTING |
1 | |
| 22 | 8M0099539 |
РУКАВ Y Fitting to Cooler HOSE Y Fitting to Cooler |
1 | |
| 23 | 815504244 |
ЗАЖИМ Червячная передача Clamp CLAMP Worm Gear Clamp |
1 | |
| 24 | 8M0107033 |
ОХЛАДИТЕЛЬ МАСЛА OIL COOLER |
1 | |
| 25 | 8M2001117 |
УПЛОТНИТЕЛЬНОЕ КОЛЬЦО (0.489 x 0.070) O-RING (.489 X .070) |
2 | |
| 26 | 8M0105201 |
КРОНШТЕЙН BRACKET |
1 | |
| 27 | 815504220 |
ЗАЖИМ Червячная передача CLAMP Worm Gear |
1 | |
| 28 | 8M0099294 |
РУКАВ HOSE |
1 | |
| 29 | 8M0082256 |
ВИНТ (M6 x 1) SCREW (M6 x 1) |
2 | superseded |
| 3 | 866725 |
ФИТИНГ Прямой (0.750-14) FITTING Straight (.750-14) |
4 | |
| 30 | 8M0086279 |
ВИНТ (M6) Cooler to Strainer SCREW (M6) Cooler to Strainer |
4 | |
| 31 | 8M0095457 |
СЕТЧАТЫЙ ФИЛЬТР В СБОРЕ STRAINER ASSEMBLY |
1 | |
| 32 | 8M0097249 |
КРЫШКА COVER |
1 | |
| 33 | 8M0087038 |
РУКАВ HOSE |
1 | |
| 34 | 815504222 |
ЗАЖИМ Червячная передача (диаметр 1.98) CLAMP Worm Gear (1.98 DIameter) |
6 | superseded |
| 35 | 8M0106990 |
РУКАВ Manifold to Heat Exchanger HOSE Manifold to Heat Exchanger |
1 | |
| 36 | 8M0106989 |
РУКАВ Manifold to Heat Exchanger HOSE Manifold to Heat Exchanger |
1 | |
| 4 | 8M0099693 |
РУКАВ Poppet to Elbow, Starboard Bottom HOSE Poppet to Elbow, Starboard Bottom |
1 | |
| 5 | 8M0099692 |
РУКАВ Poppet to Elbow, Starboard Top HOSE Poppet to Elbow, Starboard Top |
1 | |
| 6 | 8M0096712 |
РУКАВ Poppet to T Drain HOSE Poppet to T Drain |
1 | |
| 7 | 8M0096726 |
РУКАВ Poppet to T Drain HOSE Poppet to T Drain |
1 | |
| 8 | 8M2012295 |
ФИТИНГИ В СБОРЕ FITTING ASSEMBLY |
2 | superseded |
| 9 | 73379 |
ПРОБКА (.250-18) PLUG (.250-18) |
2 | superseded |
