| # | Part Number | Description | Qty | Status |
|---|---|---|---|---|
| 1 | 8M0074364 |
ПРОБКА COVER Hose Clamp |
AR | |
| 10 | 815504222 |
ЗАЖИМ Червячная передача (диаметр 1.98) CLAMP Worm Gear (1.98 DIameter) |
10 | superseded |
| 11 | 8M0082286 |
РУКАВ Steering Cooler to Y Fitting HOSE Steering Cooler to Y Fitting |
1 | superseded |
| 12 | 8M2003728 |
Y-ОБРАЗНЫЙ ФИТИНГ Y-FITTING |
1 | |
| 13 | 8M0099539 |
РУКАВ Y Fitting to Drain Fitting HOSE Y Fitting to Drain Fitting |
1 | |
| 14 | 8M0088893 |
ФИТИНГ Drain FITTING Drain |
2 | |
| 15 | 8M0099294 |
РУКАВ Drain Fitting to Strainer HOSE Drain Fitting to Strainer |
1 | |
| 16 | 8M0095457 |
СЕТЧАТЫЙ ФИЛЬТР В СБОРЕ STRAINER ASSEMBLY |
1 | |
| 17 | 8M0097249 |
КРЫШКА COVER |
1 | |
| 18 | 8M0086279 |
ВИНТ (M6) SCREW (M6) |
4 | |
| 19 | 815504232 |
ЗАЖИМ Червячная передача (диаметр 2.50) CLAMP Worm Gear (2.50 Diameter) |
4 | |
| 2 | 815504216 |
ЗАЖИМ Червячная передача (диаметр 1.56) CLAMP Worm Gear (1.56 Diameter) |
9 | |
| 20 | 8M2023913 |
РУКАВ Y Fitting to Crossover HOSE Y Fitting to Crossover |
1 | |
| 21 | 8M0087038 |
РУКАВ Strainer to Distribution Housing HOSE Strainer to Distribution Housing |
1 | |
| 22 | 8M0107045 |
ФИТИНГ Y FITTING Y |
1 | |
| 23 | 8M0098992 |
РУКАВ Drain Fitting to Y Fitting HOSE Drain Fitting to Y Fitting |
1 | |
| 24 | 8M0080675 |
РУКАВ Distribution Housing to Drain Fitting HOSE Distribution Housing to Drain Fitting |
1 | |
| 25 | 8M2023914 |
РУКАВ Y Fitting to Circulation Pump HOSE Y Fitting to Circulation Pump |
1 | superseded |
| 26 | 815504210 |
ЗАЖИМ Червячная передача CLAMP Worm Gear |
4 | |
| 27 | 8M0035079 |
РУКАВ Starboard Block Drain HOSE Starboard Block Drain |
1 | |
| 28 | 862225 |
ФИТИНГ FITTING |
2 | |
| 29 | 627021 |
УПЛОТНИТЕЛЬНОЕ КОЛЬЦО (0.301 x 0.070) O-RING (.301 x .070) |
2 | |
| 3 | 8M0099692 |
РУКАВ Connects to Upper Poppet Valve HOSE Connects to Upper Poppet Valve |
1 | |
| 30 | 862603 |
ФИТИНГ FITTING |
2 | superseded |
| 31 | 8M0035110 |
РУКАВ Exhaust Manifold to Drain Fitting HOSE Exhaust Manifold to Drain Fitting |
1 | superseded |
| 32 | 8M0098457 |
РУКАВ Crossover to Port Manifold HOSE Crossover to Port Manifold |
1 | |
| 33 | 8M0099107 |
РУКАВ Port Block Drain HOSE Port Block Drain |
1 | |
| 34 | 8M0099900 |
РУКАВ Connects to Poppet Valve; Starboard Bottom HOSE Connects to Poppet Valve; Starboard Bottom |
1 | |
| 35 | 815504244 |
ЗАЖИМ Червячная передача Cooler CLAMP Worm Gear Cooler |
1 | |
| 36 | 8M0098479 |
РУКАВ Crossover to Manifold HOSE Crossover to Manifold |
1 | superseded |
| 37 | 8M0107033 |
ОХЛАДИТЕЛЬ МАСЛА OIL COOLER |
1 | |
| 38 | 8M2001117 |
УПЛОТНИТЕЛЬНОЕ КОЛЬЦО (0.489 x 0.070) O-RING (.489 X .070) |
2 | |
| 39 | 8M0105201 |
КРОНШТЕЙН BRACKET |
1 | |
| 4 | 815504232 |
ЗАЖИМ Червячная передача (диаметр 2.50) CLAMP Worm Gear (2.50 Diameter) |
1 | |
| 40 | 8M0082256 |
ВИНТ (M6 x 1) SCREW (M6 x 1) |
2 | superseded |
| 41 | 8M0098984 |
РУКАВ Drain Fitting to Drain Fitting HOSE Drain Fitting to Drain Fitting |
1 | |
| 5 | 8M2023916 |
РУКАВ Y Fitting to Poppet Valve Cover HOSE Y Fitting to Poppet Valve Cover |
1 | |
| 6 | 8M0100541 |
РУКАВ Connects to Upper Poppet Valve HOSE Connects to Upper Poppet Valve |
1 | |
| 7 | 8M0038313 |
РУКАВ Connects to Lower Poppet Valve HOSE Connects to Lower Poppet Valve |
1 | |
| 8 | 815504212 |
ЗАЖИМ Червячная передача CLAMP Worm Gear |
5 | |
| 9 | 8M0099109 |
РУКАВ Port Manifold Drain HOSE Port Manifold Drain |
1 |
