| # | Part Number | Description | Qty | Status |
|---|
| 1 |
8M0050237 |
CAP Oil Reservoir - Black
|
1 |
superseded
|
| 10 |
89879 |
O-RING (.301 x .064)
|
1 |
|
| 11 |
8M6002411 |
CLIP
|
1 |
|
| 12 |
8M0077293 |
HOSE Oil Reservoir to Cooler
|
1 |
|
| 13 |
8M0080036 |
HOSE ASSEMBLY Bottle to Transom
|
1 |
|
| 14 |
4010616 |
SCREW (M6 x 16) Stainless Steel
|
2 |
superseded
|
| 15 |
88552616 |
SCREW (M8 x 16)
|
3 |
|
| 16 |
8M0095757 |
BRACKET
|
1 |
|
| 17 |
8M0088265 |
STRAP
|
1 |
|
| 18 |
8M0095479 |
LUBE BOTTLE ASSEMBLY
|
1 |
|
| 19 |
8067271 |
CAP Drive Lube Monitor
|
1 |
|
| 2 |
8M0046080 |
RESERVOIR ASSEMBLY Oil, Power Steering
|
1 |
superseded
|
| 20 |
72761 |
WASHER (.203 x .562 x .060) Stainless Steel
|
1 |
|
| 21 |
58376 |
SCREW (.164-18 x .375)
|
1 |
|
| 22 |
856156T04 |
SWITCH
|
1 |
|
| 23 |
69355 |
TIE STRAP (5.50 Inches)
|
1 |
superseded
|
| 24 |
8M0063382 |
CYLINDER ASSEMBLY Power Steering
|
1 |
superseded
|
| 25 |
15878 |
PIN Clevis
|
1 |
|
| 26 |
16419 |
PIN Clevis
|
1 |
|
| 27 |
46950 |
COTTER PIN
|
2 |
|
| 28 |
806232 |
O-RING (.239 x .064)
|
1 |
|
| 29 |
89879 |
O-RING (.301 x .064)
|
2 |
|
| 3 |
8M0083431 |
CLAMP
|
1 |
|
| 30 |
865415 |
FITTING
|
1 |
|
| 31 |
865414001 |
FITTING
|
1 |
|
| 32 |
865390015 |
HOSE Male Quick Connect Cylinder to Cooler
|
1 |
|
| 33 |
815504105 |
CLAMP Worm Gear (11-18 mm)
|
2 |
superseded
|
| 34 |
8M0095482 |
COOLER Power Steering
|
1 |
superseded
|
| 34 |
8M0118727 |
COOLER Power Steering DTS [2A529777] & Up
|
1 |
|
| 35 |
881879010 |
SENSOR Pressure
|
1 |
superseded
|
| 35 |
8M6000623 |
SENSOR Water Pressure Pressure (50 PSI) DTS
|
1 |
superseded
|
| 36 |
29085 |
FITTING Elbow (45 Degree)
|
1 |
superseded
|
| 36 |
59351 |
ELBOW 90 Degree DTS
|
1 |
|
| 37 |
816311 |
TIE STRAP (8.00 Inches)
|
2 |
superseded
|
| 38 |
865379 |
FITTING Female To Transom
|
1 |
|
| 39 |
815504210 |
CLAMP Worm Gear
|
1 |
|
| 4 |
F698772 |
CLAMP Worm Gear
|
1 |
|
| 5 |
8M0077292 |
HOSE Oil Pump to Reservoir
|
1 |
|
| 6 |
861578 |
PULLEY
|
1 |
superseded
|
| 7 |
4010725 |
SCREW (M8 x 25)
|
3 |
|
| 8 |
8M0095481 |
PUMP ASSEMBLY .75 Shaft Diameter
|
1 |
disc.
|
| 9 |
8M0079718 |
HOSE ASSEMBLY Pump to Cylinder
|
1 |
superseded
|
| 9 |
8M0079975 |
HOSE ASSEMBLY Pump to Cylinder Bravo FWC
|
1 |
superseded
|
| NS |
8M0089907 |
DECAL Steering Fluid
|
1 |
disc.
|
| NS |
8M0074363 |
CAP
|
1 |
|
