| # | Part Number | Description | Qty | Status |
|---|
| - |
8M0095445 |
VALVE ASSEMBLY Poppet Alpha RWC
|
1 |
|
| - |
8M0095446 |
VALVE ASSEMBLY Poppet Bravo RWC
|
1 |
|
| - |
8M0095459 |
VALVE ASSEMBLY Poppet FWC
|
1 |
|
| 1 |
4010618 |
SCREW (M6 x 18) Stainless Steel
|
2 |
|
| 10 |
69570 |
SCREW (#10-16 x .750)
|
1 |
|
| 11 |
4010625 |
SCREW (M6 x 25) Stainless Steel
|
2 |
superseded
|
| 11 |
8M0115132 |
SCREW (M6) SEMS
|
2 |
|
| 12 |
4010612 |
SCREW (M6 x 12) Stainless Steel
|
2 |
|
| 13 |
65292 |
J CLIP
|
2 |
superseded
|
| 14 |
8M0081140 |
BRACKET
|
1 |
|
| 14 |
8M0115431 |
BRACKET DTS
|
1 |
|
| 15 |
888913001 |
POPPET
|
1 |
|
| 16 |
816585 |
SCREW (.312-18 x .875)
|
2 |
|
| 17 |
8M0091668 |
PLATE Relief Valve
|
1 |
|
| 18 |
4010612 |
SCREW (M6 x 12) Stainless Steel
|
2 |
|
| 2 |
8M2020465 |
FITTING Inlet
|
1 |
|
| 3 |
45710 |
O-RING (1.424 x .103)
|
1 |
superseded
|
| 4 |
8M0032206 |
HOUSING Alpha RWC
|
1 |
|
| 4 |
8M0032643 |
HOUSING Bravo RWC
|
1 |
|
| 4 |
8M0089559 |
HOUSING FWC
|
1 |
|
| 5 |
30529 |
O-RING (1.925 x .103)
|
1 |
|
| 6 |
648771 |
DIAPHRAGM
|
1 |
|
| 7 |
90392 |
SPRING Alpha RWC
|
1 |
|
| 7 |
64878 |
SPRING (Black) Bravo RWC
|
1 |
|
| 7 |
42996 |
SPRING (Stainless Steel) FWC
|
1 |
|
| 8 |
76451 |
WASHER
|
1 |
|
| 9 |
8M0036759 |
COVER Relief Valve
|
1 |
|
