| # | Part Number | Description | Qty | Status |
|---|
| 1 |
8M0062666 |
HOSE (96.00 Inches Bulk) Cut to Length
|
1 |
|
| 10 |
815504220 |
CLAMP Worm Gear
|
1 |
|
| 11 |
8M0074364 |
COVER Hose Clamp
|
1 |
|
| 12 |
8M4501756 |
Y-FITTING
|
1 |
|
| 13 |
815504212 |
CLAMP Worm Gear
|
2 |
|
| 14 |
8M0062635 |
HOSE 42.00 inch Bulk
|
1 |
|
| 15 |
861406 |
SOCKET
|
1 |
|
| 16 |
861427 |
CAP
|
1 |
superseded
|
| 2 |
815504222 |
CLAMP Worm Gear (1.98 DIameter)
|
AR |
superseded
|
| 3 |
864727 |
FITTING Y, (3) 1-1/4 In. OD Hose Barbs Dual Drain Applications
|
AR |
|
| 4 |
8M0062666 |
HOSE (96.00 Inches Bulk) Cut to Length
|
1 |
|
| 5 |
865324 |
QUICK CONNECT
|
2 |
|
| 6 |
865362 |
QUICK CONNECT Replace if Adding Flush Kit
|
1 |
|
| 7 |
865470 |
HOUSING Inlet
|
1 |
|
| 8 |
815504228 |
CLAMP Worm Gear
|
1 |
|
| 9 |
8M2023904 |
HOSE
|
1 |
|
| NS |
8M0089505 |
FLUSH KIT
|
AR |
superseded
|
