| # | Part Number | Description | Qty | Status |
|---|
| - |
8M0095942 |
TIMING CHAIN SET
|
1 |
superseded
|
| 1 |
8M0095441 |
BRACKET Steering Pump
|
1 |
superseded
|
| 10 |
8M0082419 |
GASKET
|
2 |
|
| 11 |
8M0095436 |
PUMP ASSEMBLY Circulating
|
1 |
superseded
|
| 12 |
8M2021674 |
SCREW (.437-20 x 2.50)
|
1 |
|
| 13 |
8M0108016 |
SCREW (M8 x 1.25-16)
|
3 |
superseded
|
| 14 |
8M0095438 |
PULLEY
|
1 |
|
| 15 |
39131 |
LOCKWASHER (.437)
|
1 |
|
| 16 |
8M0082947 |
WASHER
|
1 |
superseded
|
| 17 |
8M0095437 |
HARMONIC BALANCER
|
1 |
|
| 18 |
4010618 |
SCREW (M6 x 18) Stainless Steel
|
1 |
|
| 198 |
8M0095945 |
SENSOR Crankshaft Position
|
1 |
superseded
|
| 2 |
88441430 |
SCREW (M10 x 30)
|
3 |
|
| 20 |
8M0106030 |
SCREW (M6 x 1-30)
|
6 |
superseded
|
| 21 |
8M0095944 |
COVER ASSEMBLY Timing
|
1 |
|
| 22 |
8M6002623 |
SEAL Front
|
1 |
|
| 23 |
8M0095943 |
RELUCTOR WHEEL
|
1 |
superseded
|
| 24 |
NSS |
NOT SOLD SEPARATE TIMING CHAIN
|
1 |
|
| 25 |
NSS |
NOT SOLD SEPARATE Camshaft Gear
|
1 |
|
| 26 |
NSS |
NOT SOLD SEPARATE Crankshaft Gear
|
1 |
|
| 27 |
8M0081450 |
SCREW (.312-18 x 1.34)
|
3 |
|
| 28 |
8M0069696 |
GASKET
|
1 |
|
| 29 |
8M0087881 |
BELT Alpha RWC
|
1 |
superseded
|
| 29 |
8M0074767 |
BELT Bravo RWC
|
1 |
superseded
|
| 29 |
8M0088876 |
BELT FWC
|
1 |
superseded
|
| 3 |
865597T |
TENSIONER Belt
|
1 |
|
| 30 |
8M0095458 |
PULLEY RWC
|
1 |
|
| 30 |
8M0095461 |
PULLEY FWC
|
1 |
superseded
|
| 4 |
88552630 |
SCREW (M8 x 30)
|
2 |
superseded
|
| 5 |
4010820 |
SCREW (M10 x 20) Hex Flange - Stainless Steel
|
1 |
|
| 6 |
865777 |
PULLEY
|
1 |
|
| 7 |
8M0108016 |
SCREW (M8 x 1.25-16)
|
4 |
superseded
|
| 8 |
8M0086354 |
STUD (M8 x 1.25)
|
1 |
superseded
|
| 9 |
4009560 |
SCREW
|
3 |
superseded
|
