| # | Part Number | Description | Qty | Status |
|---|
| - |
8M0088073 |
GEARCASE Complete CT Long
|
1 |
|
| - |
8M0088075 |
GEARCASE Complete CT X-Long
|
1 |
|
| - |
8M0099915 |
GEARCASE Complete CT L SeaPro
|
1 |
|
| - |
8M0099916 |
GEARCASE Complete CT XL SeaPro
|
1 |
|
| - |
8M0060147 |
SKEG
|
1 |
|
| - |
8M0088081 |
GEARCASE SEAL KIT
|
1 |
|
| 1 |
8M0057747 |
GEAR HOUSING Basic
|
1 |
|
| 1 |
8M0099907 |
GEAR HOUSING Basic SeaPro
|
1 |
|
| 10 |
8M0077490 |
CAM Shift
|
1 |
|
| 11 |
8M0094479 |
CLUTCH Sliding, 6 Jaw
|
1 |
|
| 12 |
8M0045759 |
PIN Cross
|
1 |
|
| 13 |
8M0047945 |
SPRING Retaining
|
1 |
|
| 14 |
8M0088077 |
SHAFT Propeller (RH)
|
1 |
|
| 15 |
8M0094481 |
GEAR Reverse 31T
|
1 |
|
| 16 |
860081 |
BEARING
|
1 |
superseded
|
| 17 |
8M0030779 |
THRUST RING
|
1 |
|
| 18 |
8M0030845 |
O-RING 3.975X.210
|
1 |
|
| 19 |
8M0030856 |
SPOOL Bearing Carrier
|
1 |
superseded
|
| 19 |
8M0098463 |
SPOOL Bearing Carrier
|
1 |
superseded
|
| 2 |
8M0094474 |
GEAR SET Forward/Pinion
|
1 |
|
| 20 |
30956T |
BEARING Needle
|
1 |
|
| 21 |
8M0071653 |
SCREW Special, .375-16 UNC
|
1 |
|
| 22 |
830749 |
SEAL
|
1 |
superseded
|
| 23 |
14077 |
SEAL Oil
|
1 |
|
| 24 |
76868 |
SEAL
|
1 |
superseded
|
| 24 |
12224 |
SEAL Fish Line Cutting
|
1 |
|
| 25 |
8M0030784 |
WASHER Keyed
|
1 |
|
| 26 |
8M0030785 |
RETAINER Bearing Carrier
|
1 |
superseded
|
| 27 |
8M0054695 |
SLEEVE Propeller Bore
|
1 |
superseded
|
| 28 |
8M0120367 |
ACTUATOR KIT Double Acting Shift Design 2 SeaPro [2B384875] & Up
|
1 |
|
| 29 |
8M0102962 |
ROD CLUTCH ACTUATOR
|
1 |
|
| 3 |
8M0057742 |
BEARING Needle
|
1 |
|
| 30 |
8M0029113 |
PIN Cross
|
1 |
|
| 31 |
8M0096707 |
SPRING Compression
|
2 |
|
| 32 |
8M0084245 |
PIN Spring Locator
|
1 |
|
| 33 |
824108 |
SPACER
|
1 |
|
| 4 |
8M0029306 |
RING Retaining
|
1 |
|
| 5 |
8M0057724 |
BEARING ASSY Roller, Taper
|
1 |
|
| 6 |
NSS |
NOT SOLD SEPARATE Cup
|
1 |
|
| 7 |
8M0063269 |
SHIM SET
|
1 |
|
| 8 |
8M0057749 |
ROD Clutch Actuator Design 1 [2B384874] & Below
|
1 |
|
| 9 |
8M0072550 |
FOLLOWER Cam, (RH)
|
1 |
|
