| # | Part Number | Description | Qty | Status |
|---|
| - |
8M0166001 |
GRIP ASSEMBLY
|
1 |
|
| 1 |
8M0161094 |
CHASSIS Tiller
|
1 |
|
| 10 |
8M0161124 |
BEZEL Power Trim Switch
|
1 |
|
| 10 |
8M0161145 |
BEZEL No Power Trim Switch Sea Pro
|
1 |
|
| 11 |
8M0161104 |
SCREW (M4 x 0.7 x 12), SOC FLAT HD
|
2 |
|
| 12 |
8M0161109 |
BRACKET Shift Mounting
|
1 |
|
| 13 |
8M0161113 |
SCREW M6X1.0X10
|
7 |
|
| 14 |
8M0085515 |
SCREW (#8 - 32 x .375)
|
2 |
|
| 15 |
8M0161111 |
FLANGE BUSHING
|
2 |
|
| 16 |
8M0161108 |
SHIFT LEVER
|
1 |
|
| 17 |
NSS |
NOT SOLD SEPARATE STUD
|
1 |
|
| 18 |
8M0161114 |
DETENT ASSEMBLY
|
1 |
|
| 19 |
NSS |
NOT SOLD SEPARATE SPRING
|
1 |
|
| 2 |
8M0161107 |
COVER Shift Handle
|
1 |
|
| 20 |
NSS |
NOT SOLD SEPARATE GUIDE
|
1 |
|
| 21 |
NSS |
NOT SOLD SEPARATE ROLLER
|
1 |
|
| 22 |
26811 |
COTTER PIN
|
3 |
|
| 23 |
8M0161131 |
FRICTION CLAMP
|
1 |
|
| 24 |
8M0161112 |
BRACKET Shift Mounting
|
1 |
|
| 25 |
8M0161137 |
FRICTION KNOB
|
1 |
|
| 26 |
8M0161138 |
DECAL Throttle Friction
|
1 |
|
| 27 |
8M0161136 |
COTTER PIN
|
1 |
|
| 28 |
4002316 |
WASHER (6.60 X 17.0 X 1.5SS)
|
1 |
superseded
|
| 29 |
29641 |
E RING
|
1 |
|
| 3 |
8M0161106 |
SCREW
|
1 |
|
| 30 |
8M0161258 |
PINION
|
2 |
|
| 31 |
8M0161139 |
THROTTLE GEAR ASSEMBLY
|
1 |
|
| 32 |
8M0161125 |
CLAMP
|
1 |
|
| 33 |
8M0161130 |
THROTTLE BRACKET
|
1 |
|
| 34 |
8M0161128 |
PIN Clevis
|
1 |
|
| 35 |
8M0161115 |
BRACKET HARNESS
|
1 |
|
| 36 |
8M0161134 |
WASHER
|
2 |
|
| 37 |
8M0161135 |
SCREW M4x16
|
2 |
|
| 38 |
8M0161133 |
BUSHING
|
2 |
|
| 39 |
8M0161132 |
PILLOW SUPPORT
|
1 |
|
| 4 |
4002319 |
WASHER
|
1 |
|
| 40 |
8M0161127 |
PIN Split Lock
|
1 |
|
| 41 |
8M0161129 |
THROTTLE SHAFT
|
1 |
|
| 5 |
8M0161105 |
SHIFT HANDLE ASSEMBLY
|
1 |
|
| 6 |
8M0161110 |
FLANGE BUSHING
|
1 |
|
| 7 |
8M0161126 |
THROTTLE TUBE
|
1 |
|
| 8 |
NSS |
NOT SOLD SEPARATE INNER GRIP
|
1 |
|
| 9 |
NSS |
NOT SOLD SEPARATE OUTER GRIP
|
1 |
|
