| # | Part Number | Description | Qty | Status |
|---|
| - |
8M0187303 |
GEAR HOUSING ASSEMBLY Complete, CXL, 2.04:1 (X-Long) [3B111735] & Up
|
1 |
superseded
|
| - |
830749A01 |
SEAL KIT Gear Housing
|
1 |
|
| 1 |
8M0190046 |
GEARCASE Basic [3B111735] & Up
|
1 |
|
| 10 |
NSS |
NOT SOLD SEPARATE Cup
|
1 |
|
| 11 |
23721 |
RING Retaining
|
1 |
superseded
|
| 12 |
892805 |
THRUST WASHER
|
1 |
superseded
|
| 13 |
884325T01 |
BEARING ASSEMBLY Roller-Tappered
|
1 |
superseded
|
| 14 |
NSS |
NOT SOLD SEPARATE Cup
|
1 |
|
| 15 |
884328A01 |
SHIM SET
|
1 |
disc.
|
| 16 |
30893 |
SPRING
|
1 |
|
| 17 |
880714T |
CLUTCH
|
1 |
|
| 18 |
30632 |
PIN Cross
|
1 |
superseded
|
| 19 |
828356 |
PIN Detent
|
1 |
|
| 2 |
NSS |
NOT SOLD SEPARATE Plug
|
1 |
|
| 20 |
8M0069774 |
PROPELLER SHAFT
|
1 |
superseded
|
| 21 |
884335A01 |
GEAR ASSEMBLY Forward
|
1 |
superseded
|
| 22 |
880699 |
THRUST RING
|
1 |
|
| 23 |
815480 |
BEARING Thrust
|
1 |
|
| 24 |
8M0076745 |
SHIM SET
|
1 |
|
| 25 |
8M0086846 |
CARRIER ASSEMBLY Bearing
|
1 |
|
| 26 |
896524 |
O-RING (3.850 x .210)
|
1 |
superseded
|
| 27 |
814653T |
BEARING ASSEMBLY Needle Rollers
|
1 |
|
| 28 |
880728 |
ADAPTER Bearing
|
1 |
superseded
|
| 29 |
47397A1 |
SHIM SET
|
1 |
|
| 3 |
8M0046215 |
CRANK, Shifter 1/4 Pivot Pin
|
1 |
superseded
|
| 30 |
884330T01 |
BEARING ASSEMBLY Taper
|
1 |
superseded
|
| 31 |
NSS |
NOT SOLD SEPARATE Cup
|
1 |
|
| 32 |
896600 |
SEAL Oil
|
1 |
superseded
|
| 33 |
888483 |
SEAL Oil
|
1 |
superseded
|
| 34 |
880717A01 |
SCREW/SEAL KIT
|
1 |
|
| 35 |
830749 |
SEAL
|
1 |
superseded
|
| 36 |
892818 |
ADAPTER
|
1 |
superseded
|
| 37 |
8M0064306 |
SPACER Thrust
|
1 |
|
| 38 |
880697 |
KEYED WASHER
|
1 |
|
| 39 |
79448 |
RETAINER
|
1 |
superseded
|
| 4 |
19755T7 |
SPOOL ASSEMBLY
|
1 |
superseded
|
| 40 |
NSS |
NOT SOLD SEPARATE Decal-Counter Rotation
|
1 |
|
| 41 |
896233A01 |
DRIVE SLEEVE ASSEMBLY
|
1 |
disc.
|
| 42 |
878584Q1 |
ADAPTER
|
1 |
superseded
|
| 43 |
52707T1 |
PROP NUT KIT (.750-16) (Mercury Branded)
|
1 |
|
| 43 |
52707Q1 |
PROP NUT KIT (.750-16) (Quicksilver Branded)
|
1 |
|
| 5 |
NSS |
NOT SOLD SEPARATE Spool
|
1 |
|
| 6 |
469501 |
COTTER PIN
|
1 |
|
| 7 |
NSS |
NOT SOLD SEPARATE Sleeve Adjusting
|
1 |
|
| 8 |
884337A02 |
GEAR ASSEMBLY Reverse
|
1 |
|
| 9 |
884323T01 |
BEARING ASSEMBLY Roller
|
1 |
superseded
|
