| # | Part Number | Description | Qty | Status |
|---|
| - |
8M0081029 |
KIT Extreme Duty Mount
|
1 |
|
| 1 |
8M0045781 |
SCREW M14x2.0-115 HX FLG HD
|
2 |
superseded
|
| 10 |
8M0052523 |
TRIM SENSOR ASSEMBLY
|
1 |
superseded
|
| 11 |
89302 |
WASHER (.203 x .406 x .040)
|
2 |
|
| 12 |
852368 |
SCREW (#10-24 x .750)
|
2 |
|
| 13 |
8M0057751 |
SWIVEL BRACKET ASSEMBLY Black
|
1 |
superseded
|
| 13 |
8M0230756 |
SWIVEL BRACKET ASSEMBLY Silver
|
1 |
|
| 14 |
8M0059091 |
BEARING Tilt pin 26.38IDX42LG
|
2 |
|
| 15 |
74036 |
FITTING Grease
|
1 |
superseded
|
| 16 |
8M0034861 |
BUSHING Swivel Tube Pivot
|
2 |
superseded
|
| 17 |
8M0034870 |
SEAL Swivel Tube
|
2 |
|
| 18 |
816432 |
THRUST WASHER
|
2 |
|
| 19 |
4000325 |
SCREW (M6 x 8)
|
1 |
|
| 2 |
8M0052629 |
WASHER Upper Mount Snubber
|
2 |
|
| 2 |
8M0065195 |
SCREW (M14x2x115) Hex Flange
|
2 |
|
| 20 |
8M0057726 |
YOKE Bottom
|
1 |
|
| 21 |
825190 |
WASHER
|
2 |
|
| 22 |
8M0045787 |
SCREW M14X2.00 X 155 HEX FLG HD
|
2 |
superseded
|
| 22 |
8M0069492 |
BOLT (M14x2x155) Hex Flange
|
2 |
|
| 23 |
8M0057725 |
LOWER MOUNT ASSEMBLY
|
2 |
|
| 23 |
NSS |
NOT SOLD SEPARATE Extreme Duty Lower Mounts (Only available as part of extreme duty mount kit 8M0081029)
|
2 |
|
| 24 |
8M0052453 |
WASHER Lower Mount Snubber
|
2 |
superseded
|
| 25 |
8M0045788 |
WASHER Lower Mount Snubber 14.4ID
|
2 |
superseded
|
| 25 |
8M0069499 |
WASHER
|
2 |
|
| 26 |
8M0062747 |
CABLE ASSEMBLY
|
1 |
|
| 27 |
896602 |
NUT (M14)
|
2 |
|
| 28 |
4000326 |
SCREW (M6 x 12)
|
1 |
|
| 29 |
8M0050046 |
CABLE ASSEMBLY
|
1 |
|
| 3 |
8M0047986 |
SCREW (M10X1.5X40) Hex Flange
|
6 |
superseded
|
| 3 |
8M0069689 |
SCREW (M10x1.5x40) Hex Flange
|
6 |
|
| 30 |
29245 |
WASHER (.281 x .500 x .060) Stainless Steel
|
1 |
superseded
|
| 31 |
8M0049816 |
RETAINER Trim Lead
|
1 |
|
| 32 |
8M0032692 |
FLANGED JOURNAL BEARING [2B063781] & Below
|
2 |
disc.
|
| 32 |
8M0081024 |
SPLIT JOURNAL BEARING [2B063782] & Up
|
2 |
|
| 33 |
67684 |
RING Retaining
|
1 |
|
| 34 |
8M0047986 |
SCREW (M10X1.5X40) Hex Flange
|
8 |
superseded
|
| 34 |
8M0069689 |
SCREW (M10x1.5x40) Hex Flange
|
8 |
|
| 35 |
4010610 |
SCREW (M6 x 10) Stainless Steel
|
1 |
|
| 36 |
92876A12 |
LINK ROD ASSEMBLY
|
1 |
|
| 37 |
849838 |
SCREW (.375-24 x 1.250)
|
1 |
|
| 38 |
8M0042636 |
NUT (.375-24) Brass
|
2 |
superseded
|
| 39 |
37828 |
WASHER (.390 x .625 x .062) Stainless Steel
|
2 |
|
| 4 |
8M0057723 |
MOUNT Upper
|
2 |
superseded
|
| 4 |
NSS |
NOT SOLD SEPARATE Extreme Duty Mounts (Only available as part of extreme duty mount kit 8M0081029)
|
1 |
|
| 5 |
8M0057743 |
STEERING TUBE ASSEMBLY
|
1 |
superseded
|
| 6 |
896602 |
NUT (M14)
|
2 |
|
| 7 |
847401 |
SCREW (#10-24 x .380)
|
1 |
|
| 8 |
24836 |
CLIP
|
1 |
|
| 9 |
8M0056607 |
C-WASHER
|
1 |
superseded
|
