| # | Part Number | Description | Qty | Status |
|---|
| - |
8M0057763 |
GASKET SET Powerhead
|
1 |
|
| - |
8M0057641 |
LONG BLOCK ASSEMBLY
|
1 |
superseded
|
| - |
8M0227269 |
POWERHEAD 150Hp 4-Stroke, Reman Dressed Without ECM
|
1 |
|
| - |
8M0061498 |
SHORT BLOCK ASSEMBLY
|
1 |
superseded
|
| 1 |
8M0057642 |
CYLINDER BLOCK ASSY
|
1 |
superseded
|
| 1 |
8M0122813 |
CYLINDER BLOCK ASSY Use with bearing set for {2B203614 and up}
|
1 |
|
| 10 |
NSS |
NOT SOLD SEPARATE O-ring, M2.5 X 27
|
1 |
|
| 11 |
8M0047996 |
PLUG (24 MM)
|
1 |
superseded
|
| 12 |
NSS |
NOT SOLD SEPARATE O-ring, M2 X 21
|
1 |
|
| 13 |
88552525 |
SCREW (M6 x 25 MM) Stainless Steel
|
A/R |
superseded
|
| 14 |
8M0057645 |
CRANKCASE COVER
|
1 |
|
| 15 |
8M0047548 |
SEAL Crankcase Cover
|
1 |
superseded
|
| 16 |
8M0045794 |
CAP
|
1 |
superseded
|
| 17 |
8M0045964 |
SCREW (M8 X 1.25 X 95)
|
7 |
superseded
|
| 18 |
8M0057670 |
BALANCE SHAFT ASSEMBLY
|
1 |
|
| 19 |
8M0057658 |
OIL PUMP ASSEMBLY
|
1 |
|
| 2 |
NSS |
NOT SOLD SEPARATE Bedplate
|
1 |
|
| 20 |
88552545 |
SCREW (M6 x 45 MM) Stainless Steel
|
4 |
superseded
|
| 21 |
8M0055655 |
OIL PICK UP ASSEMBLY
|
1 |
superseded
|
| 22 |
8M6000385 |
CLAMP (39.6 MM)
|
1 |
superseded
|
| 23 |
8M0055656 |
HOSE Oil Pick Up
|
1 |
|
| 24 |
8M0043913 |
THRUST WASHER
|
2 |
|
| 25 |
8M0103816 |
SCREW M8 x 50 HEX FLG
|
12 |
|
| 3 |
893540 |
PIN Dowel, 8x12 long
|
4 |
|
| 4 |
8M0045943 |
SCREW M10X1.50X95 HX FLG HD
|
10 |
superseded
|
| 5 |
8M0057644 |
DIPSTICK ASSEMBLY
|
1 |
disc.
|
| 6 |
8M0048519 |
O-RING 012, Viton
|
2 |
|
| 7 |
8M0047995 |
PLUG (18 MM)
|
1 |
superseded
|
| 8 |
NSS |
NOT SOLD SEPARATE O-ring, M2 X 15
|
1 |
|
| 9 |
8M0047997 |
PLUG (30 MM)
|
1 |
superseded
|
