| # | Part Number | Description | Qty | Status |
|---|
| - |
8M0057676 |
FUEL SUPPLY MODULE Dual Pump
|
1 |
superseded
|
| - |
8M0057679 |
FSM SEAL KIT
|
1 |
|
| 1 |
8M0053756 |
SCREW Plastite W/ HX WSR HD
|
4 |
|
| 10 |
NSS |
NOT SOLD SEPARATE Seal
|
2 |
|
| 11 |
8M0062771 |
PUMP ASSY Low Pressure
|
1 |
|
| 12 |
8M0062770 |
PUMP ASSY High Pressure
|
1 |
|
| 13 |
NSS |
NOT SOLD SEPARATE O-Ring
|
4 |
|
| 14 |
8M0053735 |
TUBE Fuel
|
2 |
superseded
|
| 15 |
8M0053755 |
TUBE Suction
|
1 |
|
| 16 |
NSS |
NOT SOLD SEPARATE O-Ring
|
4 |
|
| 17 |
8M0053734 |
TUBE Water
|
2 |
superseded
|
| 18 |
NSS |
NOT SOLD SEPARATE Seal
|
1 |
|
| 19 |
8M0053725 |
FSM BOTTOM HOUSING
|
1 |
|
| 2 |
8M0053726 |
FSM TOP HOUSING
|
1 |
superseded
|
| 20 |
8M6001398 |
ELECTRICAL HARNESS ASSEMBLY
|
1 |
superseded
|
| 21 |
NSS |
NOT SOLD SEPARATE O-Ring
|
1 |
|
| 22 |
NSS |
NOT SOLD SEPARATE O-Ring
|
1 |
|
| 23 |
NSS |
NOT SOLD SEPARATE Spacer
|
1 |
|
| 3 |
NSS |
NOT SOLD SEPARATE O-Ring
|
1 |
|
| 4 |
8M0053749 |
REGULATOR ASSEMBLY
|
1 |
|
| 5 |
NSS |
NOT SOLD SEPARATE O-Ring
|
1 |
|
| 6 |
NSS |
NOT SOLD SEPARATE O-Ring
|
1 |
|
| 7 |
NSS |
NOT SOLD SEPARATE Seal
|
3 |
|
| 8 |
NSS |
NOT SOLD SEPARATE O-Ring
|
2 |
|
| 9 |
8M0053727 |
FSM CAP
|
1 |
|
