| # | Part Number | Description | Qty | Status |
|---|
| 1 |
877761K01 |
FILTER Oil Mercury Branded
|
1 |
|
| 10 |
8M0070367 |
MOUNT - TUBULAR 8MM Component of Starter 8M0096343
|
6 |
superseded
|
| 11 |
8M0096343 |
STARTER Isolation Mount - Painted
|
1 |
superseded
|
| 12 |
8M0070369 |
SPACER (8.3 I.D. X 11.8 O.D.) Component of Starter 8M0096343
|
2 |
|
| 13 |
40011126 |
SCREW (M6 x 13) Stainless Steel
|
1 |
|
| 14 |
81893420 |
SCREW (M8 x 20)
|
1 |
|
| 15 |
8M6000634 |
PRESSURE SENSOR Oil
|
1 |
superseded
|
| 16 |
8M0056666 |
GROUND STRAP Starter
|
1 |
|
| 17 |
8M0012661 |
SCREW M6 x 14 HEX FLG SS
|
2 |
|
| 18 |
897672 |
FITTING
|
1 |
superseded
|
| 19 |
8M0070368 |
SPACER (8.3 I.D. X 11.8 O.D.) Component of Starter 8M0096343
|
1 |
|
| 2 |
8M0039451 |
TRAY Oil Filter Drain
|
1 |
|
| 3 |
8M0049906 |
PLUG Oil Tray
|
1 |
superseded
|
| 4 |
40011106 |
SCREW (M5 x 13) Stainless Steel
|
2 |
|
| 5 |
8283582 |
SENSOR Crank position
|
1 |
superseded
|
| 6 |
885342002 |
SENSOR ASSEMBLY Block water temp
|
1 |
superseded
|
| 7 |
8M0062119 |
SCREW (M8 X 80)
|
2 |
superseded
|
| 8 |
88552645 |
SCREW (M8X45)
|
1 |
|
| 9 |
43430 |
WASHER
|
3 |
|
